FANUC Series 30i/ 31i/ 32i Position Coder Selection by Address P, Specifications Additional Manual Page 2
Additional Manual
A-90045 E
Title
Draw
No.
2/5
Sheet
FANUC Series 30
i
/ 31
i
/ 32
i
Position Coder Selection By Address P
Edit
Apprv.
Desig.
Date
Design
Description
Date
Mar.25.2005
1．Outline
When the spindle is selected by address P in multi-spindle control
(MPP(No.3703#3)=1), position coder feedback is automatically selected by
address P for feed per rotation, thread cutting, and so on
2．Description
When the spindle is selected by address P in multi-spindle control
(MPP(No.3703#3)=1), position coder feedback is automatically selected by
address P.
The program of spindle selection by address P is as follows.
S_ P_
This time, address P is command for spindle selection in multi-spindle
control.
NOTE
The multi-spindle control option is required.
Contents Summary of FANUC Series 30i/ 31i/ 32i Position Coder Selection by Address P, Specifications Additional Manual
- Page 1FANUC Series 30i/ 31i/32i POSITION CODER SELECTION BY ADDRESS P Specifications Title FANUC Series 30i/ 31i/ 32i Position Coder Selection By Address P Draw A-90045 E No. Edit Date Design Description Sheet 1/5 Date Mar.25.2005 Desig. Apprv.
- Page 21．Outline When the spindle is selected by address P in multi-spindle control (MPP(No.3703#3)=1), position coder feedback is automatically selected by address P for feed per rotation, thread cutting, and so on 2．Description When the spindle is selected by address P in multi-spindle control (MPP(No.37
- Page 3・Example In the case of following program S1000 P21 ; G99 G01 Z100. F1. ; (1) 1st spindle of path-2 is commanded “S1000” (2) Path-1 selects the position coder feedback of 1st spindle of path-2 for feed per rotation. S command CNC P command P value 1st Spindle 11 Path 1 S1000 P21; 2nd Spindle 12 G99G
- Page 43．Parameters #7 #6 #5 #4 #3 #2 #1 #0 3703 MPP [Input type] Parameter input [Data type] Bit NOTE When this parameter is set, the power must be turned off before operation is continued. #3 MPP In multi-spindle control, a spindle selection using a programmed command instead of using the signals (SWS1 t
- Page 5NOTE When the parameter MPC is “1”, position coder feedback is automatically selected. This time, position coder selection signals PC2SLC
, and Path spindle feedback selection signals SLPCA
