3．Parameters
#7 #6 #5 #4 #3 #2 #1 #0
3703
MPP
[Input type] Parameter input
[Data type] Bit
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
# 3 MPP
In multi-spindle control, a spindle selection using a programmed
command instead of using the signals (SWS1 to SWS4<G027#0 to
#2,G026#3>) is:
0: Not made.
1: Made.
NOTE
When this parameter is set to 1, set parameter
No.3781 at the same time.
#7 #6 #5 #4 #3 #2 #1 #0
3713
MPC
[Input type] Parameter input
[Data type] Bit
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
# 6 MPC
When the spindle is selected by address P in multi-spindle control
(MPP(No.3703#3)=1), position coder feedback is
0: selected by position coder selection signals.
1: selected by address P.
