FANUC Series30i /31i /32i -MODEL A Machine Operation Menu Tool, Operator 's Manual Additional Manual Page 7

Additional Manual
Edit
App
rvDesi
g
.
7
/
14
Date
Design
Descri
p
tion
Data
FANUC Series30i /31i /32i -MODEL A
Machine Operation Menu Tool
O
p
erato
r
's Manual
A
-79935E/01
March.09.2005
S.Sa
g
ara
Page
Title
Draw
No.
H.Yamada
Following table shows the definable contents by a combination of soft key type and display
size.
Table 1.3 (b) Table of corresponding machine operation menu
Menu Type Vertical Horizontal
CNC Screen Size 10.4/15 Inch 10.4/15 Inch 7.2/8.4 Inch
Main Menu Number 2 pages ※１ 1 page ※2 1 page※2
Sub-Menu Number 30 pages 20 pages 20 pages
Button Number 8 10 5
Sub-Menu Group Definition Unavailable Available Available
Character Number of Soft key 6 single byte
characters
×2 Lines
12 single byte
characters
×2 Lines
6 single byte
characters
1 Line
※1 Menu Number of main menu is a fix of 10 or 11.
※2 Menu Number of main menu is a fix of 10.
RESTRICTIONS
z Only one combination of soft key type and machine display size is
possible for one MEM file.
Blocks with different soft key type (vertical/horizontal) or display size
cannot be included in one MEM file.
z Maximum size of MEM file is 128KB.
z Maximum size of 1 block is 32 KB.
