2. Specifications
In binary operation, if superimposed axis selection signal in binary operation (BNAD1~
BNAD8) is set to 1, the pulse set by the parameter No.12250 and 12251 is
superimposed on the moving amount of axis selected by these signals.
The superimposing is finished when the signal BNAD becomes 0 or binary operation is
completed.
2.1 Set up of superimposed pulse
The superimposed pulse is set as fractional number by the parameter
No.12250 and 12251.
No.12250 : Numerator of superimposed pulse (Signed)
No.12251 : Denominator of superimposed pulse (Signed)
Example) If the parameter No.12250 is set to 2 and No.12251 is set to 5, the
superimposed pulse per interpolation period becomes 0.4.
1
st
period : 2/5 pulse -> 0 pulse is output
2
nd
period : 4/5 pulse -> 0 pulse is output
3
rd
period : 6/5 pulse -> 1 pulse is output (1/5 pulse remaining)
4
th
period : 3/5 pulse -> 0 pulse is output
5
th
period : 5/5 pulse -> 1 pulse is output (0 pulse remaining)
:
In case the interpolation period is 1msec, 400 pulses per 1sec are output
5
2
5
4
5
6
5
3
5
5
5
2
5
4
5
6
5
3
…
5
5
= (0 + 0 + 1 + 0 + 1 + 0 + 0 + 1 + 0 +...+ 1) = 400
1000 counts
