FANUC Series 16i/18i/21i-TA , FANUC Series 16i/18i/21i-MT/TB, Superimposed command in Binary operation Additional Manual Page 6

Additional Manual
Edit
ApprvDesig.
Sheet
Title
Draw
No.
6/6
Date
Desig
Descri
p
tion
Date
FANUC Series16i/18i/21i–TA
FANUC Series16i/18i/21i–MB/TB
Superimposed command to Binary operation
ith M l M
A-78492EN
02 Apr.02.’01 New designed
Apr.02.’01 T.Endo H.Kochiya
5. Signals
Data No. #7#6#5#4#3#2#1#0
G0294
BNAD8 BNAD7 BNAD6 BNAD5 BNAD4 BNAD3 BNAD2 BNAD1
[Classification] Input signal
[Function] This signal selects superimposed axis in binary operation.
[Operation] When this signal in binary operation is set to 1, the pulse set by the
parameter No.12250 and 12251 is superimposed on the moving amount of
axis selected by this signal. The superimposing is finished when the signal
BNADn becomes 0 or binary operation is completed.
Data No. #7#6#5#4#3#2#1#0
F0314
BNA8O BNA7O BNA6O BNA5O BNA4O BNA3O BNA2O BNA1O
[Classification] Output signal
[Function] This signal specifies superimposed axis in binary operation.
[Operation] In binary operation, a signal corresponded to superimposed axis becomes “1”
6. Alarm
Number Message Meaning
P/S179
Parameter setting error the sum of distribution pulse and
superimposed pulse (No.12250,12251) is
over range from –32768 to +32767.
Modify the parameter setting value.
