Backup Adaptor Additional Manual Page 1
Additional Manual
TECHNICAL REPORT (MANUAL) No. TMS04 / 015
Date April 22, 2004
General Manager of
Servo Laboratory
Backup adaptor
1. Distribute this report to the destinations marked with
○
Your information
○
GE Fanuc-N, GE Fanuc-E
Fanuc Robotics-NA, Fanuc Robotics-E
CINCINNATI MILACRON
○
Machine tool builder
Sales agency
End user
2. Summary for Sales Documents (Sales guide, Functional comparison list, etc.)
3. Another Information
4. Attached Document
Drawing A-56731E-0098/01
No. (1/3- 3/3 )
5. Registration of Order List data (In case of Order List)
Type of Data
Manager Chief
Original section of issue
IDE
Contents Summary of Backup Adaptor Additional Manual
- Page 1TECHNICAL REPORT (MANUAL) No. TMS04 / 015 Date April 22, 2004 General Manager of Servo Laboratory Backup adaptor 1. Distribute this report to the destinations marked with ○ Your information ○ GE Fanuc-N, GE Fanuc-E Fanuc Robotics-NA, Fanuc Robotics-E CINCINNATI MILACRON ○ Machine tool builder Sales
- Page 2Backup adaptor 1. Type of applied technical documents Name Backup adaptor Spec. No./ Version A-56731E-0098/01 2. Summary of change New, Add Applicable Group Name/Outline Correct, Delete date Basic Function Optional Function Unit Maintenance Parts Notice Correction Backup adaptor This is the adaptor
- Page 33.Outline This backup adaptor is used for keeping the position data of αi/βi Pulsecoder in case of the maintenance of the feedback cable or the servo amplifier. The position data is kept for about ten minutes with a backup capacitor within the Pulsecoder even if the feedback cable is removed and the
- Page 46.The specifications of the applied Pulsecoder • αi Pulsecoder: A860-2000-T301, -T321, A860-2001-T301, -T321 • βi Pulsecoder: A860-2020-T301, -T321 (The Pulsecoder for the robot is not included because it doesn't have the backup capacitor) 7.The specifications of the lithium battery which is connect
