FANUC Series 16i/18i/21i -TB/MB Spindle Speed Override for Each Spindle (Improvement of Multi-Spindle Control) Additional Manual Page 4

Additional Manual
A-79118E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/18i/21i –TB/MB
Spindle speed override for each spindle
(Improvement of multi-spindle)
Sheet
4
/
5
4.Parameter
#7 #6 #5 #4 #3 #2 #1 #0
3713 EOV
[Data type] Bit, common to all path
EOV Each spindle speed override is
0: not used
1: used
NOTE 1) Multi-spindle control type C (No.3713#3=1) is necessary to use this function.
NOTE 2) When this parameter has been set, the power must be turned off before operation is
continued.
#7 #6 #5 #4 #3 #2 #1 #0
3713 MSC
[Data type] Bit, common to all path
MSC Multi-spindle control type C is
0: not used
1: used
NOTE 1) When parameter MSC and parameter MSI for multi-spindle control type B (No.3709#2) are
set at same time, multi-spindle control type C is allowed.
NOTE 2) Because the method of treatment for *SSTP and SWS signals is different, it should be
necessary to take mechanical measures such as change ladder sequence, etc. So, When
this parameter is set, please be careful.
For multi-spindle control type C, see FANUC Series 16i/18i/21i- MODEL B multi-spindle
control type C specifications (A-79114E).
NOTE 3) When this parameter has been set, the power must be turned off before operation is
continued.
