Changing of the USA Specification Main Breaker for FANUC LASER C Series Additional Manual Page 2
Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
002/4
DESCRIPTIONDESIG.DATE
01 05.07.20
Koba
y
ashi
N
ewl
y
Changing of the USA specification
main breaker for FANUC LASER C series
A-81053E-112
(3) C4000-E：Rated current 225A, Sensed current 30mA
Rated current is changed from 200A to 225A.
・Type : SG203CUL/225-30MA(made by Fuji Electric Co., Ltd.)
・FANUC purchase spec. ; A60L-0001-0427#E225BJB1
・Recommended solderless terminal
Cable size
Type Name of recommended solderless terminal／Maker
100mm
2
CB100-S8／J.S.T Mfg Co., Ltd.
CB100-8／DAIDO Solderless Terminal Industries CO., Ltd.
150mm
2
CB150-S8／J.S.T Mfg Co., Ltd.
CB150-8／DAIDO Solderless Terminal Industries CO., Ltd..
・Maker's recommended torque：10.5[N･m]
(4) C5000-E：Rated current 225A, Sensed current 30mA
・Type : SG203CUL/225-30MA(made by Fuji Electric Co., Ltd.)
・FANUC purchase spec. ; A60L-0001-0427#E225BJB1
・Recommended solderless terminal
Cable size
Type Name of recommended solderless terminal／Maker
100mm
2
CB100-S8／J.S.T Mfg Co., Ltd.
CB100-8／DAIDO Solderless Terminal Industries CO., Ltd.
150mm
2
CB150-S8／J.S.T Mfg Co., Ltd.
CB150-8／DAIDO Solderless Terminal Industries CO., Ltd..
・Maker's recommended torque：10.5[N･m]
(5) C6000-E：Rated current 300A, Sensed current 100mA
・Type : SG403CUL/300-100MA(made by Fuji Electric Co., Ltd.)
・FANUC purchase spec. ; A60L-0001-0427#F300CJD1
・Recommended solderless terminal
Cable size
Type Name of recommended solderless terminal／Maker
125mm
2
150-12／J.S.T Mfg Co., Ltd.
R150-12／NICHFU Terminal Industries CO., Ltd.
185mm
2
180-12／J.S.T Mfg Co., Ltd.
R180-12／NICHFU Terminal Industries CO., Ltd.
・Maker's recommended torque：45.0[N･m]
