About the Specification Change of the Main Breaker for FANUC LASER C Series Additional Manual Page 3

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
003/3
DESCRIPTIONDESIG.DATE
01 05.04.20
Koba
y
ashi
N
ewl
y
About the specification change of the
main breaker for FANUC LASER C series
A-81053E-100
4. Application
C1000-E is applied from the following Serial Number.
The other models are scheduled to apply from the manufacturing in June, 2005.
MODEL Application
C1000-E
L05410030L05410031
C2000-E
C4000-E
C5000-E
C6000-E
Scheduled to apply from the manufacturing in June,2005
5. Comparison of sizes of old and new breaker table
OLD NEW
C1000-E
C2000-E
C4000-E
C5000-E
C6000-E

Contents Summary of About the Specification Change of the Main Breaker for FANUC LASER C Series Additional Manual

  • Page 1About the specification change of the main breaker for FANUC LASER C series 1. Outline To improve the safety of the laser oscillator by the earth fault protection, a domestic (JPN) specification main breaker of FANUC LASER C series is changed to the earth-leakage breaker. 2. Changing Model JPN speci
  • Page 2(5) C6000-E:Rated current 300A, Sensed current 100mA ・Type : EG403C/300-100MA(made by Fuji Electric Co., Ltd.) ・FANUC purchase spec. ; A60L-0001-0424#U300EJE2 ・Recommended solderless terminal (in case of the cable 200 mm2):R200-12;J.S.T. MfgCo., Ltd, R200-12 ;NICHIFU Terminal Industries CO., Ltd . ・
  • Page 34. Application C1000-E is applied from the following Serial Number. The other models are scheduled to apply from the manufacturing in June, 2005. MODEL Application C1000-E L05410030、L05410031~ C2000-E C4000-E Scheduled to apply from the manufacturing in June,2005 C5000-E C6000-E 5. Comparison of siz
