Changing of connection in FL-C2000C, C3000D for CE marking, we report that the connection between oscillator and machine will be changed in FL-C2000C and C3000D for CE marking Additional Manual Page 3

Additional Manual
Changing of connection in
FL-C2000C• C3000D for CE marking
01 00.06.12 TOGO Newly
••• •• •••• ••
•••••••••
••••• 002/2
•Detail of signal•
SIGNAL DETAIL
ON,OFF It is not necessary to connect these terminals from now
on.
(Oscillator
s ON/OFF signal with FS16-LB.)
(Connect AC200V controlled by CNC.)
PF1,PF2 Shunt trip of main breaker in oscillator.
When it is applied DC24V(PF1:+24V•PF2:0V) to these
terminals, main breaker is tripped.
SHL1,SHL2 Shutter interlock
When these terminals are short, the shutter can be
opened.
contact capacity: DC24V•more than 1.2A.
IB1,IB2 Visible laser interlock
When these terminals are short, visible laser can be
turned on.
contact capacity: DC30V•more than 10mA.
A1,A2 Power supply for SAFETY RELAY UNIT in oscillator, and
oscillator
s ON/OFF signal.
Connect DC24V(A1:+24V•A2:0V) controlled by CNC.
power capacity: more than 250mA.
SC Shutter close state signal
When the shutter is closed, DC24V is generated on this
terminal.
connectable load capacity: DC24V•3•100mA.
Caution) Load voltage is varied by connected load.
OFI1,OFI2 OFF prohibition signal
It inhibits the power off operation of CNC in accordance
with laser oscillation sequence.
Connect power off switch of CNC in parallel.
RUN1,RUN2 Oscillator start signal
Connect the RUN switch of the operator
s panel in series.
EMS1,EMS2 Emergency stop signal
Connect the emergency stop switch of operator
s panel.
•Application•
FL-C2000C: After the oscillator manufactured in July 2000(L00720xxx).
FL-C3000D: After the oscillator manufactured in July 2000(L00730xxx).
••
••••••••••••

Contents Summary of Changing of connection in FL-C2000C, C3000D for CE marking, we report that the connection between oscillator and machine will be changed in FL-C2000C and C3000D for CE marking Additional Manual

  • Page 1TECHNICAL REPORT NO.TML 00/006E Date 27 June, 2000 General Manager of Laser Laboratory ••Changing of connection in FL-C2000C, C3000D for CE marking• •1. Communicate this report to: •••• •• Your information •• GE FANUC-NA, GE FANUC-E FANUC Robotics CINCINNATI MILACRON •• Machine tool builder Sales ag
  • Page 2Changing of connection in FL-C2000C,C3000D for CE marking We report that the connection between oscillator and machine will be changed in FL-C2000C and C3000D for CE marking. •Overview• FL-C2000C and C3000D for CE marking is provided with the terminal:XT20 to connect signals from machine. The termin
  • Page 3•Detail of signal• SIGNAL DETAIL ON,OFF It is not necessary to connect these terminals from now on. (Oscillator’s ON/OFF signal with FS16-LB.) (Connect AC200V controlled by CNC.) PF1,PF2 Shunt trip of main breaker in oscillator. When it is applied DC24V(PF1:+24V•PF2:0V) to these terminals, main brea
