FANUC Series 0i Additional Manual Page 5

Additional Manual
5
3.1. Diagnosis
The spindle motor speeds are displayed on the diagnosis screen.
1
st
spindle motor speed
718 1
st
spindle motor speed
2
nd
spindle motor speed
719 2
nd
spindle motor speed
[Data form] word
[Data unit] 1 min
-1
[Data range] 0 ~ 65535
3.2. Spindle motor speed check by PMC ladder sequence
In order to do dual spindle rotation speed check, please realize following
method.
(1)
(2)
(3)
(4)
CNC displays the actual spindle motor speed data directory from sensor
on diagnosis No.718.
PMC reads this actual spindle motor speed data by using PMC window
function (Reading Diagnosis Data : function code 33).
PMC compares this data with the reference speed, which is registered in
PMC data area.
If the actual spindle motor speed exceeds the reference speed, PMC
executes some action (for examples, emergency stop, message display,
reduce spindle override, so on).
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
/ 6
Date
Design
Description
Date
FANUC Series 0i–TB/TC
Spindle Speed Monitoring
Specification
A-79135
03.04.18
02 05.05.16
Description of 0i-TC is added.
