FANUC Series 30i/31i/32i MODEL-A, Selection of Five Optional Language, Specifications Additional Manual Page 3

Additional Manual
FD
App
l
y
Desi
g
n
Page
Title
3
/
5
Data
Desi
g
n Description
Data
FANUC Series 30i /300i /300is
Selection of Five Optional Language
A – 90475E
05.12.28
Draw
No.
1.1 SELECTION OF FIVE OPTIONAL LANGUAGE
Overview
Up to five languages is possible to select among the option languages stored in
CNC system. The displaying language can be switched only by setting parameter
among these five languages.
Detail
CNC system prepares many optional languages for displaying screen. This function
allows a MTB to select up to five languages according to the parameter among the
optional language stored in CNC system. And these selected languages and English
can be displayed.
Operator can switch the actual displaying language among the selected five
languages and English by setting on language selection screen.
NOTE
1. This function is optional function.
2. When option of this function is effective, all of other language options
become invalid.
Previous page
Next page

Contents Summary of FANUC Series 30i/31i/32i MODEL-A, Selection of Five Optional Language, Specifications Additional Manual

  • Page 1FANUC Series 30i /31i /32i MODEL-A Selection of Five Optional Language Specifications Title FANUC Series 30i /300i /300is Selection of Five Optional Language Draw No. A – 90475E FD Data Design Description Page 1/5 Data 05.12.28 Design Apply
  • Page 2CONTENTS 1.1 Selection of five optional language ············································ 3 Overview················································································································ 3 Detail ··········································································
  • Page 31.1 SELECTION OF FIVE OPTIONAL LANGUAGE Overview Up to five languages is possible to select among the option languages stored in CNC system. The displaying language can be switched only by setting parameter among these five languages. Detail CNC system prepares many optional languages for displaying
  • Page 41.2 PARAMETER #7 #6 #5 #4 #3 #2 #1 #0 3282 SPN HGL ITA CHS CHT FRE GER JPN #7 #6 #5 #4 #3 #2 #1 #0 3283 CZE SWE HUN POL POR DAN DTH 0: Language is not effective. 1: Language is effective. 1 JPN : JAPANESE 2 GER : GERMAN 3 FRE : FRENCH 4 CHT : TRADITIONAL CHINESE 5 CHS : SIMPLIFIED CHINESE 6 ITA : IT
  • Page 51.3 NOTES Refer to the detail of displaying and switching operation of display language is described in Common to Lathe System / Machining Center System USER’S MANUAL (B-63944JA/02) “12.3.10 Displaying and Switching the Display Language”. Title FANUC Series 30i /300i /300is Selection of Five Optiona
