FANUC Series 30i/31i/32i MODEL-A, Selection of Five Optional Language, Specifications Additional Manual Page 4
Additional Manual
FD
App
l
y
Desi
g
n
Page
Title
4
/
5
Data
Desi
g
n Description
Data
FANUC Series 30i /300i /300is
Selection of Five Optional Language
A – 90475E
05.12.28
Draw
No.
1.2 PARAMETER
#7 #6 #5 #4 #3 #2 #1 #0
3282 SPN HGL ITA CHS CHT FRE GER JPN
#7 #6 #5 #4 #3 #2 #1 #0
3283 CZE SWE HUN POL POR DAN DTH
0: Language is not effective.
1: Language is effective.
1JPN
:
JAPANESE
2GER
:
GERMAN
3FRE
:
FRENCH
4 CHT
:
TRADITIONAL CHINESE
5 CHS
:
SIMPLIFIED CHINESE
6ITA
:
ITALIAN
7HGL
:
KOREAN
8 SPN
:
SPANISH
9DTH
:
DUTCH
10 DAN
:
DANISH
11 POR
:
PORTUGUESE
12 POL
:
POLISH
13 HUN
:
HUNGARIAN
14 SWE
:
SWEDISH
15 CZE
:
CZECH
NOTE
1. It is necessary to cut the power supply to reflect the change in this
parameter once. After the parameter is changed, the language that
had been selected when the power supply is turned on is displayed
in language screen.
2. When six languages or more are selected, five languages become
effective in the order of the priority shown in the above table.
(example) When all parameters are “1", five language
(1:JAPANESE - 5:SIMPLIFIED CHINESE) and
ENGLISH is displayed on the language screen.
3. If language parameter is changed to 0 during displaying,
English is set to the display language after the power supply is
turned on again.
(example) When display language is Japanese, English is set to
display language after Japanese (No.3282 #0) is set to
“0” and the power supply is turned on again.
Contents Summary of FANUC Series 30i/31i/32i MODEL-A, Selection of Five Optional Language, Specifications Additional Manual
- Page 1FANUC Series 30i /31i /32i MODEL-A Selection of Five Optional Language Specifications Title FANUC Series 30i /300i /300is Selection of Five Optional Language Draw No. A – 90475E FD Data Design Description Page 1/5 Data 05.12.28 Design Apply
- Page 2CONTENTS 1.1 Selection of five optional language ············································ 3 Overview················································································································ 3 Detail ··········································································
- Page 31.1 SELECTION OF FIVE OPTIONAL LANGUAGE Overview Up to five languages is possible to select among the option languages stored in CNC system. The displaying language can be switched only by setting parameter among these five languages. Detail CNC system prepares many optional languages for displaying
- Page 41.2 PARAMETER #7 #6 #5 #4 #3 #2 #1 #0 3282 SPN HGL ITA CHS CHT FRE GER JPN #7 #6 #5 #4 #3 #2 #1 #0 3283 CZE SWE HUN POL POR DAN DTH 0: Language is not effective. 1: Language is effective. 1 JPN : JAPANESE 2 GER : GERMAN 3 FRE : FRENCH 4 CHT : TRADITIONAL CHINESE 5 CHS : SIMPLIFIED CHINESE 6 ITA : IT
- Page 51.3 NOTES Refer to the detail of displaying and switching operation of display language is described in Common to Lathe System / Machining Center System USER’S MANUAL (B-63944JA/02) “12.3.10 Displaying and Switching the Display Language”. Title FANUC Series 30i /300i /300is Selection of Five Optiona
