FANUC Series 16
i
–MA/MB
1 path display in 2 path control Sprcifications
A
-79246EN
Drawing No.
Title
Page
2 path display (the program check screen)
1 path display (the program screen)
Note
The alarm screen always become 2 path display type independently of
parameter SDP (No. 3193 # 1).
Limitation
This function is available only in case of 2 path control with 10.4
inches LCD (Soft key 12 pieces type).
Previous page
Next page

Contents Summary of FS 16i-MA/MB Additional Manual

  • Page 1FANUC Series 16i-MA/MB 1 path display in 2 path control Specifications Contents 1 GENERAL................................ GENERAL ................................................................ ................................................................................................ ........
  • Page 21 path display in 2 path control 1 General The position screen and the program check screen become 2 path display type in case of 2 path control with 10.4 inches LCD (Soft key 12 pieces type). This function enables 1 path display type in these screens. 2 Details When parameter SDP (No. 3193 # 1) is
  • Page 32 path display (the program check screen) 1 path display (the program screen) Note The alarm screen always become 2 path display type independently of parameter SDP (No. 3193 # 1). Limitation This function is available only in case of 2 path control with 10.4 inches LCD (Soft key 12 pieces type). Ti
  • Page 43 Signal Path selection signal (Tool post selectionsignal) HEAD [Classification] Input signal [Function] Selects whether the MDI panel is used for path 1 or path 2. [Operation] 1: When this signal turned to “1”, operations performed using the MDI panel are for path 2. 2: When this signal tu
