FANUC Series 30i-MODEL A
Input of tool offset value measured B
3019
Address to which the PMC axis control skip signal and measurement
position arrival signals are assigned
Note
When this parameter is set, the power must be
turned off
before operation is continued.
[Input type] Parameter input
[Data type] Word path
[Valid data range] 0 to 727
Set an X address to which the PMC axis control skip signal ESKIP and the measurement
position arrival signals (XAE, YAE, and ZAE (M series) or XAE and ZAE (T series)) are
to be assigned.
Example 1. In case of No.3012=5
、
No.3019=6
If parameter XSG(No.3008#2) is set to 1, skip signal for PMC axis control , measurement position arrival
signal, tool offset write signal are assigned to X0006. skip signal is assigned to X0005.
#7 #6 #5 #4 #3 #2 #1 #0
X005 SKIP SKIP6 SKIP5 SKIP4 SKIP3 SKIP2 SKIP8 SKIP7 （Ｔ）
#7 #6 #5 #4 #3 #2 #1 #0
SKIP SKIP6 SKIP5 SKIP4 SKIP3 SKIP2 SKIP8 SKIP7 （M）
#7 #6 #5 #4 #3 #2 #1 #0
X006 ESKIP -MIT2 +MIT2 -MIT1 +MIT1 ZAE XAE （Ｔ）
#7 #6 #5 #4 #3 #2 #1 #0
ESKIP ZAE YAE XAE （M）
Example 2. In case of No.3012=5
、
No.3019=5
If parameter XSG(No.3008#2) is set to 1, skip signal for PMC axis control , measurement position arrival
signal, tool offset write signal, skip signal is assigned to X0005.
#7 #6 #5 #4 #3 #2 #1 #0
X005 ESKIP -MIT2 +MIT2 -MIT1 +MIT1 ZAE XAE
SKIP
SKIP6 SKIP5 SKIP4 SKIP3 SKIP2 SKIP8 SKIP7
（Ｔ）
#7 #6 #5 #4 #3 #2 #1 #0
ESKIP ZAE YAE XAE
SKIP
SKIP6
SKIP5 SKIP4 SKIP3
SKIP2 SKIP8 SKIP7
（M）
Note
This parameter is valid when bit 2 (XSG) of parameter
No. 3008 is set to 1.
Depending on the option configuration of the I/O
Link, the actually usable X addresses are:
X0 to X127, X200 to X327, X400 to X527, X600 to
X727
