Additional Manual
TITLE
DRAW
.
No.
5 / 5
Page
FANUC LTD
DESCRIPTIONDESIGNDATE
EDIT
SPINDLE AMPLIFIER
α
series
Motor over-heat detection adapter
for SPINDLE MOTOR αi series
A
-53866E-0388
6. Order information
Specification number Notes
A06B-6078-H002 Connector for the cable is not
attached.
03
01.06.22
本頁追加
Contents Summary of Alpha Spindle Amplifier Motor Overheat Detection Adapter for Alpha i Spindle Motor Additional Manual
- Page 1SPINDLE AMPLIFIER α series Motor over heat detection adapter for SPINDLE MOTOR αi series 1. General This Document describes about Motor over heat detection adapter, which is used to connect αi series SPINDLE MOTOR to α series SPINDLE AMPLIFIER MODULE. This adapter has a function that it detect an ov
- Page 23. Connection 3.1. General connection Insert overheat detection adapter between feedback cable of Spindle sensor (Mi, MZi, BZi) when connect α series SPINDLE AMPLIFER to αi series SPINDLE MOTOR. αseries SPM TYPE1 JY2B JY2A Mi sensor: K14 K72 Motor overheat MZi sensor : K17 JY2 detecting adapter TB2
- Page 3Detail of K72 SPM JY2 JY2B Shield (1) MZ MZ (1) (2) *MZ *MZ (2) (5) MA MA (5) (6) *MA *MA (6) (7) MB MB (7) (8) *MB *MB (8) (20) 5V 0.5mm2 5V (20) (16) 0V 0.5mm2 0V (16) (13) OH1 OH1 (13) (15) OH2 OH2 (15) (10) SS SS (10) Specification of Cable: 0.18mm2 twisted 4 pair + 0.5 mm2 Recommend cable: A66L
- Page 44. Specific setting for motor Install setting pin TM1, TM2, TM3 for model of motor. (Only one pin is attached) Model of motor TM1 TM2 TM3 Notes α0.5i to α3i B none none initial setting α6i to α40i none B none none none B none none A Caution: Spindle motor may not be protected if this pin is not set
- Page 56. Order information Specification number Notes A06B-6078-H002 Connector for the cable is not attached. SPINDLE AMPLIFIER α series TITLE Motor over-heat detection adapter for SPINDLE MOTOR αi series DRAW. No. A-53866E-0388 03 01.06.22 本頁追加 EDIT DATE DESIGN DESCRIPTION FANUC LTD Page 5/5
