INTRODUCTION
This manual describes the connecting information of the Fanuc Intelligent Terminal Type 1
function (I.T.) of the following FANUC CNC. This manual also provides maintenance
information (block diagrams and drawing numbers of printed circuit board(PCB), etc.).
Use this manual together with the operator
’
s manual, the connecting and maintenance manual for the
following FANUC CNC.
Application
Product Name Abbreviation
FANUC Series 150-Model B 150-B Series 150-B
FANUC Series 160-Model B 150-B Series 160-B
FANUC Series 180-Model B 150-B Series 180-B
FANUC Series 210-Model B 150-B Series 210-B
Refer to the following TECHNICAL REPORT which describes the FANUC High Speed Serial Bus and the
interface board for CNC.
Name Spec.
Connecting and Maintenance Manual for FANUC High Speed Serial Bus A-72923E
ATTENTION
●The copyright of MS-DOS and other software provided with the I.T. is owned by Microsoft Corporation
(U.S.A.), Chips and Technologies, Inc. (U.S.A.), IBM Corporation, (U.S.A.), Matsushita Electric Industrial
Co.,Ltd, and Fanuc Limited.
●No part of the software described above, or its manuals, may be used or reproduced without permission.
●No part of the software described above, or its manuals, may be sold independently of the I.T.
●The software described above, and its manual, must be used under the conditions described in the attached
license agreement.
●The use of the CNC incorporating the I.T. shall imply that the user agrees to the conditions of the license
agreement described above.
*IBM is a registered trademark of IBM corporation, USA
*Windows95 is a registered trademark of Microsoft corporation, USA
*Company name and product name mentions in this manual are (registered) trademark of each
companies.
02
03
10.14.9
08.05.9
Hiroham
Nishi
001
/
43
01
06.09.9
Kumakur
All
p
a
g
es chan
g
ed
11,12 / 43
