Series 16i/18i/21i Additional Manual Page 4

Additional Manual
・ Time chart
Time chart
workpiece coordinate system
preset completion
Each axis workpiece coordinate system
preset complete signal WPSFn
(n = 1
∼
control axis)
Each axis workpiece coordinate
system preset signal WPRSTn
Fig.1 Time chart
・ Signal address
CNC→PMC
#7 #6 #5 #4 #3 #2 #1 #0
G358 WPRST8 WPRST7 WPRST6 WPRST5 WPRST4 WPRST3 WPRST2 WPRST1
PMC→CNC
#7 #6 #5 #4 #3 #2 #1 #0
F358 WPSF8 WPSF7 WPSF6 WPSF5 WPSF4 WPSF3 WPSF2 WPSF1
4 Note
• When this function is used on FS21i-MB/TB, PMC-SB7 is necessary.
• This function has the same limitations of the workpiece coordinate preset function by
the program command (G92.1/G50.3(T series)) / MDI operation.
As for the details, please refer to OPERATOR’S MANUAL (B-63524EN,
B-63534EN, B- B-63554EN, B-63604EN, B-63614EN).
A-79104E
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/18i/21i –MB/TB, 18i –MB5
Each axis workpiece coordinate system preset
signal Specifications
2004.03.26
02 2004.06.07 02) part changed
4/4
