Series 21i/210i/210is - TA Operators manual Page 750

Operators manual

Page of 809

/ 809

APPENDIX

B–63084EN/02

G. ALARM LIST

735

Number ContentsMessage

752 FIRST SPINDLE MODE CHANGE

FAULT

This alarm is generated if the system does not properly terminate a

mode change. The modes include the Cs contouring, spindle position-

ing, rigid tapping, and spindle control modes. The alarm is activated if

the spindle control unit does not respond correctly to the mode change

command issued by the NC.

754 SPINDLE–1 ABNORMAL TORQUE

ALM

Abnormal first spindle motor load has been detected.

762 SECOND SPINDLE MODE

CHANGE FAULT

Refer to alarm No. 752. (For 2nd axis)

764 SPINDLE–2 ABNORMAL TORQUE

ALM

Same as alarm No. 754 (for the second spindle)

772 SPINDLE–3 MODE CHANGE

ERROR

Same as alarm No. 752 (for the third spindle)

774 SPINDLE–3 ABNORMAL TORQUE

ALM

Same as alarm No. 754 (for the third spindle)

782 SPINDLE–4 MODE CHANGE

ERROR

Same as alarm number 752 (for the fourth spindle)

784 SPINDLE–4 ABNORMAL TORQUE

ALM

Same as alarm number 754 (for the fourth spindle)

The details of spindle alarm No. 750 are displayed in the diagnosis display

(No. 409) as shown below.

409

#6 #5 #4 #3

SPE

S2E

S1E

SHE

#3 (SPE) 0 : In the spindle serial control, the serial spindle parameters fulfill the

spindle unit startup conditions.

1 : In the spindle serial control, the serial spindle parameters do not fulfill

the spindle unit startup conditions.

#2 (S2E) 0 : The second spindle is normal during the spindle serial control startup.

1 : The second spindle was detected to have a fault during the spindle

serial control startup.

#1 (S1E) 0 : The first spindle is normal during the spindle serial control startup.

1 : The first spindle was detected to have a fault during the spindle axis

serial control startup.

#0 (SHE) 0 : The serial communications module in the CNC is normal.

1 : The serial communications module in the CNC was detected to have a

fault.

D The details of spindle

alarm No.750
