FANUC Series 30i-MODEL A
Touch panel control
Outline
A display unit with a touch panel enables you to operate soft keys by
touching the screen.
Moreover, an application using a touch panel can be created with the C
language executor.
- Remarks
・ With a CNC of LCD-mounted type, RS-232C serial port 2 (JD36A) is
occupied.
・ With a CNC of stand-alone type, a serial port dedicated to a touch panel
is used.
・ Touch panel pressing information is read at intervals of 32 msec.
・ A positional precision of ±2.5 mm is provided.
C language executor
With the C language executor, touch panel functions can be used. For the
specifications of the functions, refer to "C Language Executor Programming
Manual".
Calibration
When replacing the touch panel or clearing all memory (SRAM) data, set
data for calibrating the positional relation between the touch panel and LCD
according to the procedure below.
Calibration procedure
1) Enable the touch panel calibration screen.(Set bit 5 (DCL) of
parameter No. 3113 to 1.)
2) Press function key
SYSTEM
.
3) Press the continuous menu key
several times. The [TOUCH
PANEL] soft key is displayed.
4) Press the [TOUCH PANEL] soft key then the [(OPRT)] soft key.
The [TP CAL] soft key is displayed.
