Series 30i-MODEL A, Touch Panel Control Additional Manual Page 6
Additional Manual
A-79349E
Title
Draw
No.
Ed. Date Design Description
Date Feb.10.’04 Design. Apprv.
4/5
page
FANUC Series 30i-MODEL A
Touch panel control
7) After entering the calibration points (9 points), press the <INPUT>
key to complete calibration. To cancel calibration or retry, press
the <CAN> key. The screen display returns to the previous screen.
If the <INPUT> key is pressed before entering the calibration points
(9 points), calibration operation is cancelled.
8) When calibration is terminated normally, the message
"CALIBRATION WAS ENDED." is displayed.
9) Upon completion of calibration, disable the touch panel calibration
screen to protect against operation errors. (Set bit 5 (DCL) of
parameter No. 3113 to 0.)
NOTE
1. If the screen display is switched from the touch
panel calibration screen to another screen such as
the alarm screen by the automatic screen switching
function, calibration is automatically cancelled.
2. Calibration operation can be performed in any
mode.
3. After system startup, perform calibration operation
swiftly before starting operation.
Parameter
#7 #6 #5 #4 #3 #2 #1 #0
3113 DCL
[Input type] Parameter input
[Data type] Bit
# 5 DCL The touch panel calibration screen is:
0: Disabled.
1: Enabled.
Usually, set this parameter to 0. Touch panel calibration becomes
necessary only when the touch panel is replaced or all memory data is
cleared. Set this parameter to 1 only when performing touch panel
calibration. Upon completion of touch panel calibration, reset this
parameter to 0.
#7 #6 #5 #4 #3 #2 #1 #0
3119 DDS
[Input type] Parameter input
[Data type] Bit
# 2 DDS The touch panel is:
0: Enabled.
1: Disabled.
Set this parameter to 1 when disabling the touch panel temporarily as in the
case of startup.
