  2. FANUC Series 30i/ 31i/ 32i Spindle Speed Override for each Spindle (Improvement of Multi-Spindle Control), Specifications

FANUC Series 30i/ 31i/ 32i Spindle Speed Override for each Spindle (Improvement of Multi-Spindle Control), Specifications Additional Manual Page 2

Additional Manual
A-90046E
Title
Draw
No.
2/6
Sheet
FANUC Series 30
i
/ 31
i
/ 32
i
Spindle speed override for each spindle
Edit
Apprv.
Desig.
Date
Design
Description
Date
Apri
l.16.2005
S.Miyake
S.Miyake
2005.05.31
The error in writing is corrected.
(2)
02
1.General
During this function, each spindle speed can be overridden individually.
An override value to 0%~254% can be applied. This function can be used
when multi-spindle control type C (parameter MSC (No.3713#3)) is set.
This function requires multi-spindle control option.
2.Specification
When each spindle speed override function(parameter EOV(No.3713#4) =1)
is effective, the specifications is as following.
- Override signals for each spindle are following.
SOV0 to 7 : Override signal for first spindle
SOV20 to 27 : Override signal for second spindle
SOV30 to 37 : Override signal for third spindle
SOV40 to 47 : Override signal for fourth spindle
- Each spindle speed can be overridden individually because an independent
override can be applied to each spindle.
Fig.1 Parameter EOV(No.3713#4)=0
Fig.2 Parameter EOV(No.3713#4)=1
3rd spindle
2nd spindle
1st spindle
4th spindle
override
SOV0~7
SOV0~7
SOV20~27
SOV30~37
SOV40~47
S command
S command
override
1st spindle
override
override
override
2nd spindle
3rd spindle
4th spindle
