FANUC Series 30i/ 31i/ 32i Spindle Speed Override for each Spindle (Improvement of Multi-Spindle Control), Specifications Additional Manual Page 5

Additional Manual
A-90046E
Title
Draw
No.
5/6
Sheet
FANUC Series 30
i
/ 31
i
/ 32
i
Spindle speed override for each spindle
Edit
Apprv.
Desig.
Date
Design
Description
Date
Apri
l.16.2005
S.Miyake
S.Miyake
2005.05.31
The error in writing is corrected.
(2)
02
5.Parameter
#7 #6 #5 #4 #3 #2 #1 #0
3713
EOV MSC
[Input type] Parameter input
[Data type] Bit
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
# 3 MSC Multi-spindle control type C is
0: not used
1: used
NOTE
When parameter MSC and parameter MSI for
multi-spindle control type B (No.3709#2) are set at
same time, multi-spindle control type C is allowed.
# 4 EOV Each spindle speed override is
0: not used
1: used
NOTE
Multi-spindle control type C (No.3713#3=1) is necessary
to use this function.
#7 #6 #5 #4 #3 #2 #1 #0
3708
TSO
[Input type] Parameter input
[Data type] Bitpath
# 6 TSO During a threading or tapping cycle, the spindle override is:
0: Disabled (tied to 100%).
1: Enabled.
NOTE
During rigid tapping, the override is tied to 100%,
irrespective of the setting of this parameter.
