6.Note
- The multi-spindle control option is necessary to use this function.
- In the case of parameter SOV (No.3106#5) (the spindle override value is
displayed)=1, 1st spindle speed override value is displayed.
- During constant surface speed control, the spindle speed is overridden
after it is clamped at the value specified in the maximum spindle speed
clamp command (G50S_ for T series and G92S_ for M series). So,
please be careful because the actual spindle speed may exceed the value
specified in the spindle speed clamp command.
Parameter SOC (No.3708#5)(during constant surface speed control, the
speed clamp is carried out after spindle speed override) is disabled. Even
if this parameter is set, above note is not changed.
But above limit to the spindle speed (No.3772) can be applied to clamp
the spindle speed.
- During this function, there is a function to fix the override to 100%
during tapping cycle mode (G84,G74 for M series and G84,G88 for T
series) and thread cutting mode (G33 for M series and G32,G92,G76 for
T series). If spindle override is changed, the parameter
TSO(No.3708#6) set to 1.
- Parameter No.5131(setting chamfering angle in threading cycle) can not
be used. Please set 0 to this parameter.
- Set an override value to 100% for spindles whose speeds are not
specified override.
- The spindle override isn't effective in the spindle which is controlled
spindle speed with PMC.
(2)
Contents Summary of FANUC Series 30i/ 31i/ 32i Spindle Speed Override for each Spindle (Improvement of Multi-Spindle Control), Specifications Additional Manual
- Page 1FANUC Series 30i/ 31i/ 32i Spindle speed override for each spindle (Improvement of multi-spindle control) Specifications Title FANUC Series 30i/ 31i/ 32i Spindle speed override for each spindle Draw A-90046E No. 02 2005.05.31 S.Miyake The error in writing is corrected. (2) Edit Date Design Descripti
- Page 21.General During this function, each spindle speed can be overridden individually. An override value to 0%~254% can be applied. This function can be used when multi-spindle control type C (parameter MSC (No.3713#3)) is set. This function requires multi-spindle control option. 2.Specification When ea
- Page 3And, in the case of spindle control on multi path, each spindle speed can be overridden by this function, too. Below figures show the example, all spindles of 2 paths system are controlled by S command of path 2. 1st spindle#2 1st spindle#1 S command 2nd spindle#2 override 2nd spindle#1 SOV0#2~7#2 3
- Page 43.Signals 1st spindle speed override signal SOV0 to SOV7
2nd spindle speed override signal SOV20 to SOV27 3rd spindle speed override signal SOV30 to SOV37 4th spindle speed override signal SOV40 to SOV47 [Classification] Input signal [Function] In the case of parameter EO - Page 55.Parameter #7 #6 #5 #4 #3 #2 #1 #0 3713 EOV MSC [Input type] Parameter input [Data type] Bit NOTE When this parameter is set, the power must be turned off before operation is continued. #3 MSC Multi-spindle control type C is 0: not used 1: used NOTE When parameter MSC and parameter MSI for multi-sp
- Page 66.Note - The multi-spindle control option is necessary to use this function. - In the case of parameter SOV (No.3106#5) (the spindle override value is displayed)=1, 1st spindle speed override value is displayed. - During constant surface speed control, the spindle speed is overridden after it is cla
