  2. Element of Decomposition of Oil Mist for Fanuc Laser C Series

Element of Decomposition of Oil Mist for Fanuc Laser C Series Additional Manual Page 6

Additional Manual
9．Exchange of the Element of Decomposition of Oil Mist
・ The life of the Element of Decomposition of Oil Mist is approx.10000 hours. Please
exchange every 10000 hours.
・ The Element of Decomposition of Oil
Mist(C1000-E:A290-4514-V170,C2000-E:A290-4523-V170,C4000-E:A290-4540-V170) is
adjusted a center position in the process of manufacture. For this reason, please don't
exchange only a catalyst (ceramic tube). Please be sure to exchange the whole of the
Element of Decomposition of Oil Mist.
02 20030313 T.WATANABE
C1000-E,C2000-E addition
01 20030217 T.WATANABE
1st edition
DRAW. NO.
Ａ－81053E－034
CUST.
EDIT DATE DESIG. DESCRIPTION APPRO.
FANUC LTD
SHEET
005／5
TITLE
Element of Decomposition of Oil Mist
for FANUC LASER C series
Previous page
Next page

Contents Summary of Element of Decomposition of Oil Mist for Fanuc Laser C Series Additional Manual

  • Page 1TECHNICAL REPORT(MANUAL) NO. TML 03/003E Date 24 June, 2003 General Manager of Laser Laboratory The modification for improvement of reliability and maintainability 1. Communicate this report to: ○ Your information only ○ GE Fanuc-N, GE Fanuc-E FANUC Robotics MILACRON ○ Machine tool builder Sales age
  • Page 2ELEMENT OF DECOMPOSITION OF OIL MIST for FANUC LASER C series 1．Outline The Element of Decomposition of Oil Mist that decomposes oil mist in resonator is added to the C1000-E,C2000-E and C4000-E to decrease the resonator mirror pollution, and to extend the mirror cleaning cycle. Please maintain the
  • Page 33．Order Parts ①In case of addition newly C4000-E C2000-E C1000-E Specification Q'ty Specification Q'ty Specification Q'ty Elem. of Decompos. A290-4540-V170 2 A290-4523-V170 2 A290-4523-V170 2 of Oil Mist A98L-0001-0619 O-ring JB-OR4D-G45 2 JB-OR4D-G45 2 2 #2031 Sticker A370-1146-0575 1 A370-1146-057
  • Page 45．Procedure of additon of the Element of Decomposition of Oil Mist newly. (C4000-E) ① Get the mode barn of laser beam before exchange or installation of the Element of Decomposition of Oil Mist. ② Stop the cooling water by not only shut down of electrical power but shut off the valve of water line.
  • Page 58．About the display which shows that the Element of Decomposition of Oil Mist has already been applied. The sticker (Figure 4) shows that the Element of Decomposition of Oil Mist and other parts for enhancement of reliability and maintainability are installed in the oscillator. And it is pasted in t
  • Page 69．Exchange of the Element of Decomposition of Oil Mist ・The life of the Element of Decomposition of Oil Mist is approx.10000 hours. Please exchange every 10000 hours. ・The Element of Decomposition of Oil Mist(C1000-E:A290-4514-V170,C2000-E:A290-4523-V170,C4000-E:A290-4540-V170) is adjusted a center
