Series 30i-MODEL A, Single Direction Positioning Additional Manual Page 5

Additional Manual
A-79358E
Title
Draw
No.
Ed. Date Design Description
Date
Jan.06.’04 Desig. Apprv.
3/7
Sheet
FANUC Series 30i-MODEL A
Single Direction Positioning
Explanation
An overrun and a positioning direction are set by the parameter (No. 5440).
Even when a commanded positioning direction coincides with that set by the
parameter, the tool stops once before the end point.
G60, which is an one-shot G-code, can be used as a modal G-code in group
01 by setting 1 to the parameter (No. 5431 bit 0 G60).
This setting can eliminate specifying a G60 command for every block.
Other specifications are the same as those for an one-shot G60 command.
When an one-shot G code is specified in the single direction positioning
mode, the one-shot G command is effective like G codes in group 01.
(Example)
When one-shot G60 commands When modal G60 command
are used. is used.
: :
: :
G90; G90 G60; Single direction
G60 X0 Y0; X0 Y0; positioning mode start
G60 X100; Single direction X100; Single direction
G60 Y100; positioning Y100; positioning
G04 X10; G04 X10;
G00 X0 Y0; G00 X0 Y0; Single direction
positioning mode
cancel
