  2. FS 16i/18i/21i-MA/MB/TA/TB, 18i-MB5, Periodical secondary pitch error compensation

FS 16i/18i/21i-MA/MB/TA/TB, 18i-MB5, Periodical secondary pitch error compensation Additional Manual Page 9

Additional Manual
5. Note
1 Using the appropriate parameters, set the number of
the most distant periodical secondary pitch
compensation point on the - side of each axis and the
number of the most distant periodical secondary pitch
compensation point on the +side of each axis. If the
settings of these two parameters are 0 or the same,
periodical secondary pitch error compensation is not
applied.
2 The number of compensation points that can be used
in pitch error compensation and periodical secondary
pitch error compensation is 0 to 1023. The number of
compensation points that can be used in pitch error
compensation decreases by the number of
compensation points used in periodical secondary
pitch error compensation.
3 When interpolated pitch error compensation is used,
the pitch error compensation amount is output in
interpolated form in each periodical secondary pitch
error compensation interval.
4 Periodical secondary pitch error compensation is
superimposed even on rotation axis pitch error
compensation.
5 The sum of the periodical secondary pitch error
compensation amounts per rotation must always be
set to 0.
6 Periodical secondary pitch error compensation cannot
be used for an axis for which spindle positioning is
performed.
7 Periodical secondary pitch error compensation is
enabled after a reference position return.
8 This function is an option function. And this function
requires “Stored pitch error compensation” option.
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Description
Date
FANUC Series 16i/18i-MA/MB, 18i-MB5
FANUC Series 16i/18i-TA/TB
Periodical secondary pitch error compensation
A-78868E
2003.04.11
Egashira
8/8
