FANUC Series 16i/18i/21i FOCAS1/HSSB PORT2 function Additional Manual Page 2

Additional Manual
1
Edit
A
pprvDesig.
Sheet
Title
Draw
No.
/
11
Date
Design
Descri
p
tion
Date
FANUC Series16i /18i /21i
FOCAS1/HSSB PORT2 function
A-77931E
1999.11.05 E.Genma H.Kozai
Contents
1. Outline .................................................................................................................... 2
2. Setting method of 2nd HSSB board....................................................................... 2
3. Functions on 2nd HSSB board .............................................................................. 2
4. Restrictions on 2nd HSSB board ......................................................................... 10
5. Notes .................................................................................................................... 11
6. Applied software series/edition ............................................................................ 11
FANUC Series 16i/ 18i/ 21i
FOCAS1/HSSB PORT2 function
Specification
1999.11.26
02
T.Watanabe
Function lists are added.
Previous page
Next page

Contents Summary of FANUC Series 16i/18i/21i FOCAS1/HSSB PORT2 function Additional Manual

  • Page 1TECHNICAL REPORT (MANUAL) ＮＯ．ＴＭＮ9９ ＮＯ．ＴＭＮ ９/168E Date: Nov. 26, 1999 General Manager of Software Laboratory FANUC Series 16i /18i /21i FOCAS1/HSSB PORT2 function 1. Communicate this report to: Your information ○ GE Fanuc-N, GE Fanuc-E FANUC Robotics CINCINNATI MILACRON ○ Machine tool builder Sales a
  • Page 2FANUC Series 16i/ 18i/ 21i FOCAS1/HSSB PORT2 function Specification Contents 1. Outline ....................................................... 2. Setting method of 2nd HSSB board...................................... 3. Functions on 2nd HSSB board ......................................... 4. Restri
  • Page 31. Outline In the past, it was possible to attach only one HSSB board. But by this function, it is possible to connect 2 personal computers by attaching 2 HSSB boards to one CNC. On the each personal computer, it is possible to read and write the various CNC data by using data window libraries, whic
  • Page 4( 7) cnc_srvdelay Read servo delay value ( 8) cnc_accdecdly Read acceleration/deceleration delay value ( 9) cnc_rddynamic Read all dynamic data (10) cnc_wrrelpos Set origin/preset relative axis position (11) cnc_prstwkcd Preset work coordinate (12) cnc_rdmovrlap Read manual overlapped motion value (
  • Page 5(20) cnc_delete Delete specified program (21) cnc_rdprogdir Read program directory (22) cnc_rdprogdir2 Read program directory(2) (23) cnc_rdproginfo Read program information (24) cnc_rdprgnum Read program number under execution (25) cnc_rdseqnum Read sequence number under execution (26) cnc_seqsrch
  • Page 6(18) cnc_wrset Write setting data (19) cnc_rdsetr Read setting data(area specified) (20) cnc_wrsets Write setting data(area specified) (21) cnc_rdsetinfo Read setting data information (22) cnc_rdsetnum Read minimum, maximum, total number of setting data (23) cnc_rdpitchr Read pitch error compensatio
  • Page 7CNC: Function related to tool life management data Function name Brief description ( 1) cnc_rdgrpid Read tool life management data (tool group number) ( 2) cnc_rdngrp Read " (number of tool groups) ( 3) cnc_rdntool Read " (number of tools) ( 4) cnc_rdlife Read " (tool life) ( 5) cnc_rdcount Read " (
  • Page 8(34) cnc_wrgrpinfo2 Write " (tool group information 2) (35) cnc_rdgrpinfo3 Read " (tool group information 3) (36) cnc_wrgrpinfo3 Write " (tool group information 3) CNC: Function related to history data Function name Brief description ( 1) cnc_stopophis Stop logging operation history data ( 2) cnc_st
  • Page 9(10) cnc_rdsynerrrg Read synchronous error for spindle adjustment(rigid tapping mode) (11) cnc_rdspdlalm Read spindle alarm for spindle monitor (12) cnc_rdctrldi Read control input signal for spindle monitor (13) cnc_rdctrldo Read control output signal for spindle monitor (14) cnc_rdwaveprm Read wav
  • Page 10(24) cnc_getpath Get path number(for 4 axes lathes, multi-path) (25) cnc_setpath Set path number( " ) (26) cnc_getdtailerr Get detail error for CNC (27) cnc_gettimer Get calendar timer of CNC (28) cnc_settimer Set calendar timer of CNC (29) cnc_clralm Clear CNC alarm CNC: Function related to PMC Fun
  • Page 11board is written. 2) CNC screen display function (It is not possible to display on the 1st HSSB and 2nd HSSB at the same time.) 3) BOP (Basic Operation Package) function (It is not possible to display / set on the loader control board.) 4) DNC operation / M198 command - DNC operation I/O channel = 1
  • Page 125. Notes 1) FOCAS1/ETHERNET (DNC1/ETHERNAT, FACTOLINK/ETHERNAT) can not be specified at the same time with this function. 2) Option assembly A1 is required. And this function requires 1 unit of DRAM (128Kb). 6. Applied software series/edition Boot software : 60M2-12 or later CNC software : FS16i-MA
