  2. FANUC Series 16i/18i/21i FOCAS1/HSSB PORT2 function

FANUC Series 16i/18i/21i FOCAS1/HSSB PORT2 function Additional Manual Page 9

Additional Manual
8
Edit
A
pprvDesig.
Sheet
Title
Draw
No.
/
11
Date
Design
Descri
p
tion
Date
FANUC Series16i /18i /21i
FOCAS1/HSSB PORT2 function
A-77931E
1999.11.05 E.Genma H.Kozai
(10) cnc_rdsynerrrg Read synchronous error for spindle adjustment(rigid tapping mode)
(11) cnc_rdspdlalm Read spindle alarm for spindle monitor
(12) cnc_rdctrldi Read control input signal for spindle monitor
(13) cnc_rdctrldo Read control output signal for spindle monitor
(14) cnc_rdwaveprm Read waveform diagnosis parameter
(15) cnc_wrwaveprm Write waveform diagnosis parameter
(16) cnc_wavestart Start sampling waveform diagnosis data
(17) cnc_wavestop Stop sampling waveform diagnosis data
(18) cnc_wavestat Read sampling status of waveform diagnosis data
(19) cnc_rdwavedata Read waveform diagnosis data
CNC: Function related to Others
Function name Brief description
( 1) cnc_sysinfo Read CNC system information
( 2) cnc_rdsyssoft Read series/version of CNC system software
( 3) cnc_rdmdlconfig2 Read module configuration of CNC system (2)
( 4) cnc_statinfo Read CNC status information
( 5) cnc_alarm Read alarm status
( 6) cnc_rdalminfo Read alarm information
( 7) cnc_modal Read modal data
( 8) cnc_diagnoss Read diagnosis data
( 9) cnc_diagnosr Read diagnosis data(area specified)
(10) cnc_rddiaginfo Read diagnosis data information
(11) cnc_rddiagnum Read minimum, maximum, total number of diagnosis data
(12) cnc_adcnv Read A/D conversion data
(13) cnc_rdopmsg Read operator's message
(14) cnc_rdopmsg2 Read operator's message (2)
(15) cnc_rdprstrinfo Read program restart information
(16) cnc_rstrseqsrch Search sequence number for program restart
(17) cnc_rdopnlsgnl Read output signal image of software operator's panel
(18) cnc_wropnlsgnl Write output signal of software operator's panel
(19) cnc_rdopnlgnrl Read general signal image of software operator's panel
(20) cnc_wropnlgnrl Write general signal image of software operator's panel
(21) cnc_rdopnlgsname Read general signal name of software operator's panel
(22) cnc_wropnlgsname Write general signal name of software operator's panel
(23) cnc_getfigure Read maximum valid figures, number of decimal places
