FS16/18-C, FS16i/18i-A Detailed Servo Alarms and Spindle Alarms Displaying (A-62226E/A-60529) Additional Manual Page 6

Additional Manual
Edit
A-60529E
FS16/18-MC
/
TC , FS16i
/
18i
/
21i -MA/T
A
The improvement of spindle alarm
messages
2
/
4
Title
Drawin
No.
Pa
g
e
Date Si
g
nature Descri
p
tion
1997/01/11
T.Inagaki T.Masuda
02 980414 Made an overall revision
1. Specifications
1.1. Outline
This is the function that is improved in displaying spindle alarm message.
1.2. Detailed specifications
In previous spindle alarm messages were displayed as follows.
characters of alarm message：32 characters
751 FIRST SPINDLE ALARM DETECT (AL-**)
Alarm messages meant spindle numbers and alarm contents of the spindle
amplifier(AL-**). Alarm numbers were divided into 751 , 761 , 771 , and 781 , by
spindle numbers.
Now , spindle alarm messages became improved in respects that alarm messages
and numbers became divided by spindle alarm contents in addition to spindle
numbers. These new messages are displayed as follows.
characters of alarm message：32 characters
Alarm No. SPN_n_:Alarm Message
7 chars 　　25 chars
Alarm numbers are divided as follows.
7101～7199：first spindle alarm (AL-01～99)
7201～7299：second spindle alarm (AL-01～99)
7301～7399：third spindle alarm (AL-01～99)
7401～7399：forth spindle alarm (AL-01～99)( only in i-series )
Lower two digits of these new alarm numbers are consistent with alarm numbers of
spindle amplifiers(AL-**).
In the page 4, the list of new alarm messages is indicated. By the way, the alarm
number whose alarm message isn’t defined is shown as 7n**.(n indicates a spindle
number , and ** indicates an alarm number of an spindle amplifier.)
