FS 16i/18i/21i-A/B, Setting Method of the Ethernet default address Supplement to Manual Page 4

Supplement to Manual
3
Edit
Apprv.Desig.
Sheet
Title
Draw
No.
/ 5
Date
Desi
g
n
Descri
p
tion
Date
FANUC Series16i/18i/21i-A/B
Setting method of
the Ethernet default address
A-78770EN
2002.05.09
Kageyama
(17) In case that the Ethernet default address is set to Ethernet board, when “1” is displayed on
the 7-segment LED, press the push switch.
When Ethernet board is invalid, “1” is not displayed on the 7-segment LED.
(18) In case that the Ethernet default address is set to embedded Ethernet, when “2” is displayed
on the 7-segment LED, press the push switch.
When embedded Ethernet is invalid, “2” is not displayed on the 7-segment LED.
(19) In case that the Ethernet default address is set to PCMCIA Ethernet, when “3” is displayed
on the 7-segment LED, press the push switch.
When PCMCIA Ethernet is invalid, “3” is not displayed on the 7-segment LED.
(20) Selected number blinks on the 7-segment LED, and then press the push switch.
(21) When default address setting is finished with no errors, “0” is displayed on the 7-segment
LED.
If some error occurs during default address setting, “o” is displayed on the 7-segment LED.
(22) When press the push switch, fourth selection mode is selected and the 7-segment LED is
changing from “0” to “F”.
(23) When “F” is displayed on the 7-segment LED, press the push switch.
(24) “F” blinks on the 7-segment LED.
(25) When press the push switch, all operation is finished. “0” is displayed on the 7-segment LED.
All operation shows as follows.
Primary Secondary Third Fourth Explanation
0 End of this operation
0 Return to primary selection mode
0 Return to secondary selection mode
0 Return to third selection mode
1 The default address is set to Ethernet board.
2 The default address is set to embedded Ethernet.
3 The default address is set to PCMCIA Ethernet.
3
F End of all operation
1
F End of all operation
7
F End of all operation
