  2. FS 16i/18i/21i-MA/TA, Automatic Operation and Temporary Storage of External Program

FS 16i/18i/21i-MA/TA, Automatic Operation and Temporary Storage of External Program Supplement to Manual Page 10

Supplement to Manual
5.Parameters
Data No.
Data
12011
Head of program number of temporary part program
Data type 2-Word
Valid Data
range
1-99999999
Data No.
Data
12012
End of program number of temporary part program
Data type 2-Word
Valid data
range
1-99999999
These parameters sets that the range of part program number on
temporary storage memory. The other program number becomes part
program number on part program storage memory.
Example)
No.12011 = 7,000
No.12012 = 7,999
Part program on temporary storage memory : O7000 -
O7999
Part program on part program storage memory :O0001 -
O6999
O8000-
O9999
(Note1) This parameters can not be change if any part program is registered on
CNC.
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
10
/
10
Date
Design
Descri
p
tion
Date
FANUC Series16i/18i/21i–MA/TA
Automatic operation and temporary
storage of external program
ith M l M
A
-78620
09.Oct.’01 T.Endo H.Kochiya
Previous page
Next page

Contents Summary of FS 16i/18i/21i-MA/TA, Automatic Operation and Temporary Storage of External Program Supplement to Manual

  • Page 1FANUC Series 16i /18i /21i – MA/TA Automatic operation and temporary storage of external program Index 1. Genaral........................................................................................................................... 2 2. Specifications ...........................................
  • Page 21.General In this function, the programs in Data Server or a memory card are temporarily registered into the temporary storage memory on CNC and executed. These programs can be executed as same as these in the part program storage memory without Custom Macro limitation. (Ex. WHILE DO statement) The
  • Page 32. Specifications 2.1 Size of temporary storage memory The maximum size of registrable program is 9500m for the size of the part program storage memory and the temporary storage memory together. Size of the temporary part program storage memory = 9,500m - size of the part program storage The free me
  • Page 4on CNC. Example) No.12011 = 7,000 No.12012 = 7,999 Part program on the temporary storage memory : O7000 - O7999 Part program on the part program storage memory : O0001 - O6999 O8000 - O9999 2.3 Display of program directory screen The “O” number of part program on the temporary storage memory is disp
  • Page 5Used the number of part programs on the part program storage memory : 100 Number of registerable part program on the temporary storage memory : 300 2.5 Program edit of part program on the temporary storage memory It is possible to edit the part program on the temporary storage memory as same as part
  • Page 6M code for program deletion M296 P ”program number” It is possible to delete the program on the temporary storage memory by M296 command. If the specified program does not exist on the temporary storage memory, M296 command is ignored. Deletion of all programs can not be commanded by M296 command. I
  • Page 73.Example In case that the parameters are set as follows. No.12011 = 7,000 No.12012 = 7,999 : M298 P7000 ; Request to register O7000 from I/O device into the temporary storage memory. : G01 X_; These blocks are executed while O7000 is X_; been registered by M298 command. X_; M297 ; Wait until regist
  • Page 84.Notes (1) This function is available on 1 path Milling system, 1 path and 2 path turning system, but not available on 2CPU3 paths system and compound machining system. (2) It is not possible to exchange the program number between the part program storage memory and the temporary storage memory. If
  • Page 9(11) When the macro variables #20000 – are used in the macro executor function, the useable part program storage memory decreases. But the useable temporary part program storage memory dose not increase. (12) This function can not use with the embedded macro function. FANUC Series16i/18i/21i–MA/TA T
  • Page 105.Parameters Data No. Data 12011 Head of program number of temporary part program Data type 2-Word Valid Data 1-99999999 range Data No. Data 12012 End of program number of temporary part program Data type 2-Word Valid data 1-99999999 range These parameters sets that the range of part program number
  • Page 11(Note2) This parameters are used as the same number as the embedded macro function. This function can not be used with the embedded macro function. FANUC Series16i/18i/21i–MA/TA Title Automatic operation and temporary storage of external program Draw ith M lM No. A-78620 Edit Date Design Description
  • Page 12Data No. Data 12017 M code for registering part program into temporary storage memory Data type Word Valid data 1-999 range This parameter sets the M code which instructs to register part program into temporary storage memory. If the parameter is set to 0, M298 is used. Data No. Data 12018 M code fo
