Connection Manual FOR Relay module A Additional Manual Page 3
Additional Manual
EDIT DATE DESIG.
TITLE
DESCRIPTION
DRAW NO
A-80035E
SHEET
CUST
3
/
8
.
3. Connection of Each Part
3.1 Pin Assignment
Terminal and Connector pin assignment of the Relay Module A.
XT1 XP1 XP2
2COM1
4COM1
6COM1
8COM2
10 COM2
12 COM3
14 COM3
16 COM4
18 COM4
20 COM4
22 COM5
24 COM6
26 COM6
28 COM6
30 COM7
32 COM7
34 COM8
36 COM8
38 COM8
40 +24E
1 KA1A
3 KA1C
5 KA2A
7 KA2C
9COM2
11 KA3A
13 KA34C
15 KA4A
17 KA5A
19 KA56C
21 KA6A
23 COM5
25 KA7A
27 KA7C
29 KA8A
31 KA8C
33 KA9A
35 KA9C
37 KA10A
39 KA10C
A01 +24E B01 +24E
A02 B02
A03 B03 Yn+0.2
A04 Yn+0.6 B04 Yn+0.0
A05 Yn+1.0 B05 Yn+0.1
A06 Yn+1.2 B06 Yn+0.3
A07 Yn+0.5 B07 Yn+0.7
A08 Yn+1.1 B08 Yn+1.3
A09 Yn+1.4 B09 Yn+1.4
A10 Yn+1.5 B10 Yn+1.5
A11 Yn+1.6 B11 Yn+1.6
A12 Yn+1.7 B12 Yn+1.7
A13 B13
A14 B14
A15 B15
A16 B16
A17 B17
A18 Yn+0.4 B18
A19 B19
A20 B20
A21 B21
A22 B22
A23 B23
A24 0V B24 0V
A25 0V B25
A01 +24E B01 +24E
A02 B02
A03 B03 Yn+1.4
A04 Yn+1.6 B04 Yn+1.2
A05 Yn+1.7 B05 Yn+1.3
A06 B06 Yn+1.4
A07 Yn+1.5 B07 Yn+1.6
A08 Yn+1.7 B08
A09 B09
A10 B10
A11 B11
A12 B12
A13 B13
A14 B14
A15 B15
A16 B16
A17 B17
A18 Yn+1.5 B18
A19 B19
A20 B20
A21 B21
A22 B22
A23 B23
A24 0V B24 0V
A25 0V B25
XT1 connecting wire
Solid : 0.2-6.0mm
2
Stranded : 0 .2-4.0mm
2
AWG : AWG24-10
Stranded with ferrules : 0.5-4.0mm
2
(without/with plastic collar)
Stripping length : 8mm
XP1, XP2 connector specification of flat cable side is
HIF3BA-20D-2.54R
