Enhanced specification for Step 3 Additional Manual Page 3

Additional Manual
2. Rough specifications of the new and the enhanced features
SeriesNo
.
Feature Drawing
No.
Specifications
MA MA
(MA)
Comments
1 Remote buffer A02B-
0261-J700
By connecting Host computer or
Input/output device via Serial
interface, it is possible to rapidly and
continuously provide mass data to
CNC.
○○
Refer to FS15i/150i-MA
Remote Buffer Complement
Specifications B-63322EN-
1/02.
Macro executor A02B-
0261-J717
It is possible to change custom macro
programs made by MTB to P-CODE
macros and register them into F-
ROM(FLASH ROM) and run them.
○○
Refer to FS15i/150i-MA
Macro Compiler / Executor
Programming Manual B-
63323EN-2, which will be
issued soon.
Macro executor
user program area
512KB
A02B-
0261-J607
P-CODE file size for macro executor
can be extended to 512Kbyte.
○○
Macro executor
user program area
1MB
A02B-
0261-J640
P-CODE file size for macro executor
can be extended to 1Mbyte.
○○
Remote
diagnostic
function
BASIC Using PC as a service station, it is
possible to input/output various data
of CNC connected to telephone line.
○○
Refer to FANUC Series
15i/16i/18i/21i Remote
Diagnostic Function Host
Software (for Windows)
Specifications, attached.
MODEM card
control
BASIC MODEM card is available at the slot
on the display unit.
○○
Multi-language
display A
A02B-
0261-J614
Germany, Italian and French are
available for display.
○○
Multi-language
display B
A02B-
0261-J603
Spanish and Swedish are available
for display.
○○
Name
No.
FANUC Series 15i-MA/150i-MA
Enhanced s
p
ecifications
(
Ste
p
3
)
A-77844E/01
Page
2/4
Newly registered
Ver  Date Design Description
01 99.08.05 Sano

Contents Summary of Enhanced specification for Step 3 Additional Manual
