Enhanced specification for Step 3 Additional Manual Page 4

Additional Manual
SeriesNo
.
Feature Drawing
No.
Specifications
MA MA
(MA)
Comments
DNC Operation
from Memory card
interface
BASIC DNC operation is possible with file on
Memory card.
Note The speed of reading
program on Memory card is about
80% of that on the program memory
in CNC.
○○
10 Enhancement of
Smooth
interpolation
Included in
A02B-
0261-J839
Conditions to turn on/off Smooth
interpolation are enhanced. Setting
the conditions are easier than that of
the conventional Smooth
interpolation..
○○
11 Tool length
compensation in
tool axis direction
with Twin Table
control
Included in
A02B-
0261-J611
During Twin Table control, Tool length
compensation in tool axis direction is
possible.
○○
12 Enhancement of
Position switch
Included in
A02B-
0261-J906
To judge the range of Position
switches, the servo delay(position
error) and the Acc/Dec delay can be
regarded.
○○
13 Skip position on
program
coordinate system
during 3
dimensional
coordinate system
conversion
Included in
A02B-
0261-J651
When custom macro system
variables #5061#5080(ABSKP) are
read during 3-dimensional coord.
System conversion, the values on
program coord.(after conversion) can
be read.
○○
14 Brightness
adjustment screen
for monochrome
display unit with
g
ra
p
hic function
BASIC In the case of monochrome display
unit with graphic function, the
brightness of background and cursor
and the reverse of cursor can be set..
○○
Name
No.
FANUC Series 15i-MA/150i-MA
Enhanced s
p
ecifications
(
Ste
p
3
)
A-77844E/01
Page
3/4
Newly registered
Ver  Date Design Description
01 99.08.05 Sano

Contents Summary of Enhanced specification for Step 3 Additional Manual
