FANUC Series 16i/18i/21i-B Simplified Chinese Additional Manual Page 5
Additional Manual
5
Edit
Apprv
Desig.
Sheet
Title
Draw
No.
/
6
Date
Desig
Description
Dat
e
FANUC Series16
i
/18
i
/21
i
-B
Simplified Chinese
A
-
76584E
2003.11.07
S.Isohata
02
2005.05.26
SAITO
The head of MACRO ALARM was added
2. Simplified Chinese display in macro alarm
2.1. Outline
When the macro alarm message of system variable #3000 is
displayed, the thing to display Simplified Chinese can be done.
Moreover, it is also possible to use Simplified Chinese and a part
of ASCII code half-size character at the same time by one
instruction. The code that can be specified is a half-size character
code of 20H -9FH.
This function is a conversation macro, a auxiliary macro, an
execution macro, and available. Moreover, the influence on the
mode specified by the conversation macro is not received.
(Always become Simplified Chinese display)
2.2.
Specification
Simplified Chinese is specified by an international code while it is
(" ") following the expression to substitute the alarm number for
system variable # 3000 when Simplified Chinese is specified by
the macro alarm message display. The macro alarm display can be
displayed with Simplified Chinese by executing this instruction.
Example) When you display Chinese Simplified Chinese
“ ” as an alarm message.
#3000=10("BAEA B3CC D0F2 B1A8 BEAF");
Simplified Chinese comes to be displayed on the alarm message
screen by instructing like the above-mentioned and executing it.
Contents Summary of FANUC Series 16i/18i/21i-B Simplified Chinese Additional Manual
- Page 1FANUC Series 16i / 18 i / 21 i -B Specification Simplified Chinese Title FANUC Series16i /18i/21i -B Simplified Chinese Draw No. A-76584E 02 2005.05.26 SAITO The head of MACRO ALARM was added Edit Date Desig Description Sheet 1/ 6 Date 2003.11.07 Desig. S.Isohata Apprv
- Page 2FANUC Series 16 i /18 i/21 i -B Specification Simplified Chinese Contents 1. Simplified Chinese display by conversation macro 3 1.1. Outline 3 1.2. Specification 3 2. Simplified Chinese display in macro alarm 5 1.1. Outline 5 1.2. Specification 5 3. Notes 6 Title FANUC Series16i /18i/21i -B Simplifi
- Page 31. Simplified Chinese display by conversation macro 1.1 Outline The thing to display a Simplified Chinese can be done in the conversation macro. Moreover, it is also possible to use half-size character of a Simplified Chinese and a part of ascii code at the same time by a command once. The code whic
- Page 4Example2) When instructing in a Simplified Chinese and half-size character at the same time. G240 K1; G243 X10. Y10. (ABC) (“B0A2”) ( ) (“D7D6”); ABC S P A C E ( half-size) It is displayed at the position of character coordinate system (10,10) as follows when instructing like this. Simplified Chines
- Page 52. Simplified Chinese display in macro alarm 2.1. Outline When the macro alarm message of system variable #3000 is displayed, the thing to display Simplified Chinese can be done. Moreover, it is also possible to use Simplified Chinese and a part of ASCII code half-size character at the same time by
- Page 63. Notes When a Simplified Chinese is not selected in the display mode on the NC system side as for this function, a Simplified Chinese cannot be displayed even if DISPLAY specification of a Simplified Chinese character-code is done in the conversation macro. Title FANUC Series16i /18i/21i -B Simpli
