1. Fanuc
  2. High Resolution Serial Output Circuit

High Resolution Serial Output Circuit Additional Manual Page 5

Additional Manual
High Resolution Serial Output
Circuit
4 9
FANUC LTD
A-56731E-0079
DescriptionDesig.DateEdit.
01 97.01.30 MAEDA Taniguchi
title
Sheet
Draw. No.
(4)-2 Available Linear Encoders(Analog signal output type)
Encoder Maker Encoder
Name
pitch of
sinful
m)
Maximum
Velocity(m/min.)
Scale Length
(mm)
HEIDENHAIN LS486 20 120 70 2040
HEIDENHAIN LS186 20 120 240 3040
HEIDENHAIN LB381 100 120 440 30040
HEIDENHAIN LF481 4 48 50 1220
HEIDENHAIN LT181 20 120 60
HEIDENHAIN LIP481 2 24 10 420
HEIDENHAIN LIF181 4 48 70 3040
HEIDENHAIN LIDA185 40 480 140 30040
MITUTOYO AT402 20 120 100 3000
MITUTOYO AT211 (Note) 20 120 100 1500
OPTODYNE LDS 40.513167 240 1016 50800
RENISHAW RGBF 20 120 50000
FUTABA FMV 8, 20 48, 120 100 2200
FUTABA FTV 20 120 75 1200
SONY PRECISION
TECHNOLOGY
SH12 20 120 70 1240
SONY PRECISION
TECHNOLOGY
SH52 20 120 120 2270
(Note) Special analog output type to be specified.
*HEIDENHAIN’s linear encoders with distance-coded reference marks are not available.
*The encoder maker is responsible for the performance and guarantee of the encoder.
Please inquire the details of the encoder maker.
Available encoders added Taniguchi02 2001.5.24 Kikuchi
