FS 16i/18i/21i-TB/MB, FS 18i-MB5, FS 16i/18i-TA/MA, Expansion of Custom Macro Interface Signal Additional Manual Page 9

Additional Manual
#7 #6 #5 #4 #3 #2 #1 #0
G0284 UI307 UI306 UI305 UI304 UI303 UI302 UI301 UI300
G0285 UI315 UI314 UI313 UI312 UI311 UI310 UI309 UI308
G0286 UI323 UI322 UI321 UI320 UI319 UI318 UI317 UI316
G0287 UI331 UI330 UI329 UI328 UI327 UI326 UI325 UI324
[Classification] Input Signal
[Function] The statuses of interface signals are available by reading the system variable #1035.
Available when the parameter MIF(No.6001#0)="1".
Interface Output Signals assigned to the Custom Macro Variables
PMC <- CNC
#7 #6 #5 #4 #3 #2 #1 #0
F0054 UO007 UO006 UO005 UO004 UO003 UO002 UO001 UO000
F0055 UO015 UO014 UO013 UO012 UO011 UO010 UO009 UO008
F0276 UO023 UO022 UO021 UO020 UO019 UO018 UO017 UO016
F0277 UO031 UO030 UO029 UO028 UO027 UO026 UO025 UO024
[Classification] Output Signal
[Function] Interface signals can be transmitted by assigning values to the system variables
#1100-#1131 and #1132.
Available when the parameter MIF(No.6001#0)="1".
#7 #6 #5 #4 #3 #2 #1 #0
F0280 UO207 UO206 UO205 UO204 UO203 UO202 UO201 UO200
F0281 UO215 UO214 UO213 UO212 UO211 UO210 UO209 UO208
F0282 UO223 UO222 UO221 UO220 UO219 UO218 UO217 UO216
F0283 UO231 UO230 UO229 UO228 UO227 UO226 UO225 UO224
[Classification] Output Signal
[Function] Interface signals can be transmitted by assigning values to the system variables #1134.
Available when the parameter MIF(No.6001#0)="1".
Ed.
Page
Name
No.
Date
Contents
Draw up
FS16
i
/18
i
/21
i
-TB/MB/TA/MA
Expansion of Custom Macro Interface Signal
A-61002E
2002.09.12
9/10
