Retrace Function with AI Contour Contorl Additional Manual Page 2

Additional Manual
Edit
A
pprvDesig.
Sheet
Title
Draw
No.
Date
Desi
g
n
Descri
p
tion
Date
FS-16i/18i
Synchronous control
Specifications for messer Griesheim
A-63554E-9
K.Miyajima
1999.06.26
Egashira
02
1999.11.01
Revision for mark *2 K.Miyajima
2/6
Egashira
1. Outline
This function enables the synchronous operation of two torch heads with the program for
single head. It is also possible to drive each head individually. And Mirror Image function can
be applied to the each head by PMC DI signal.
2. Operation
2. 1 Setting of axes
It is necessary to set parameters as follows.
Axis Number Axis Name Axis Attribute
1
st
XX axis master
2
nd
YY axis master
3
rd
CC axis master
4
th
AA axis master
5
th
U X axis slave
6
th
V Y axis slave
7
th
W C axis slave
8
th
B A axis slave
Parameter NO.
1
st
2
nd
3
rd
4
th
5
th
6
th
7
th
8
th
NO. 1020 88 89 67 65 85 86 87 66
NO. 1022 1 2005600
NO. 8311 0 0001234
For the detail, please refer “3. Parameters” .
