Notice of the revision of Digital Servo ROM 90A3 Series (A-63639E-050/A-63639E-034) Additional Manual Page 22

Additional Manual
Title 9083 / 9087 / 90A3 / 90A7
Learning Control Operator’s Manual
Draw No.
02 ‘99.01.14 K.Maeda Qualified 1’st issue
A - 63639E - 034
01 ‘97.12.08 K.Maeda Newly designed Sheet 019
Edit Date Design Description / 069
2198
JAINBL Special Hunting control gain (Extra semi-closed) 9087/A
2199
JTOVL Special Hunting control conversion coefficient 9087/A
2230
IPPIL Current IP or PI coefficient
2231
MSCKLV Maximum speed check level
2232
STPRPT Step repetition count Don’t use. fix to 0
2233
PRFNO Profile number
2234
LESTTM Learning start time
2235
RPTCT2 2
nd
repetition count (cycle)
2236
PRIOD2 2
nd
Learning period (msec)
2237
RPTCT3 3
rd
repetition count (cycle)
2238
PRIOD3 3
rd
Learning period (msec)
2239
RPTCT4 4
th
repetition count (cycle)
2240
PRIOD4 4
th
Learning period (msec)
2241
SFTTH1 Manual thinning count Don’t use. fix to 0
2242
RPTCT 1
st
repetition count (cycle)
2243
PRIOD 1
st
Learning period (msec)
2244
FBND Frequency band of the low pass filter (Hz)
2245
BRCT Learning suspension cycle (cycle)
2067
FILTER Tcmd filter coefficient
2110
MGSTCM Magnetic saturation compensation coefficient 9083/A
2175
RSHFTL R-phase current offset compensation coefficient
2176
SSHFTL S-phase current offset compensation coefficient
2177
Cut-off frequency for resonance eliminate filter (Hz) 90A3/B
2113
Center frequency for resonance eliminate filter (Hz) 90A3/B
