  2. Notice of the revision of Digital Servo ROM 90A3 Series (A-63639E-050/A-63639E-034)

Notice of the revision of Digital Servo ROM 90A3 Series (A-63639E-050/A-63639E-034) Additional Manual Page 64

Additional Manual
Title 9083 / 9087 / 90A3 / 90A7
Learning Control Operator’s Manual
Draw No.
02 ’99.01.14 K.Maeda Qualified 1’st issue
A - 63639E - 034
01 ‘97.12.08 K.Maeda Newly designed Sheet 061
Edit Date Design Description / 069
3 / 5
Standard Special
9
0
7
0
9
0
8
0
9
0
9
0
9
0
A
0
9
0
7
3
9
0
8
3
9
0
8
7
9
0
A
3
9
0
A
7
MP Scale for Alpha Pulco - - - C - - - - -
N Pulse Suppress A A C A A A A A A
Nano meter interpolation - - - - - - - -
New current saturation - - - - -
New G/A (SALF2) available - - J B - - - B A
Non linear control A A C A A A A A A
Notch filter A A C A - - - B
Notch filter 500us C A C A - - - B
Observer coefficient 10 times C A C A A A A A A
Observer function A A C A A A A A A
Observer function disable at stop H A C A - A A A A
OVC Alarm improvement - E C A - A A A A
OVC Alarm release - P F A - B A
OVC data output by Check-board - - - - - - - - -
Overshoot compensation (error range) A A C A A A A A A
Overshoot compensation (TYPE-2) K C A - - - - -
Parameter Alarm detail output - N C A -
Phase delaying comp. at deceleration - M C A - B A A
Phase leading comp. depended on Tcmd A A C A A - - - -
Pitch error compensation S D - - - - -
Position FB output by Check-board C A C A A A A A A
Position gain change (cutting/rapid) - - - - -
PWM period changing (cutting/rapid) - - - - - -
Quick stop at OVC Alarm or OVL Alarm - - E - - -
Radius error data output by Check-board A A C A - - - - -
Resonance eliminate filter - - E - - - B
Rewrite Amplifier ID - - F A - - - B A
Runaway Alarm - A C A - A A A A
Runaway Alarm improvement - F C A - A A A A
Semi-Full Alarm at Full-closed - K C A - - - - -
Serial Communication delay compensation S
Serial pulse coder dummy function E A C C A A A A A
Servo tuning screen(actual speed etc.) A A C A A A A A A
Shortening Stop distance at hard disconnect - N E A -
Static friction compensation A A C A A A A A A
Switching between IP and PI for Laser D A C A - - - - -
Switching semi-closed or full-closed under dual position FB - U - - - - -
Tandem control function A A C A - B - B A
Tandem control function (2 axes use common feedback) A C A - B - B A
Tandem control function (damping compensation) A C A - - - B A
Tandem control function (full preloaded function) A C A - - - - -
Tandem control function (switching of position feedback) A C A - - - - -
Tandem control function (velocity tandem control) D A C A - - - B A
Torque coefficient down compensation - S -
