  2. Notice of the revision of Digital Servo ROM 90A3 Series (A-63639E-050/A-63639E-034)

Notice of the revision of Digital Servo ROM 90A3 Series (A-63639E-050/A-63639E-034) Additional Manual Page 66

Additional Manual
Title 9083 / 9087 / 90A3 / 90A7
Learning Control Operator’s Manual
Draw No.
02 ’99.01.14 K.Maeda Qualified 1’st issue
A - 63639E - 034
01 ‘97.12.08 K.Maeda Newly designed Sheet 063
Edit Date Design Description / 069
5 / 5
Standard Special
9
0
7
0
9
0
8
0
9
0
9
0
9
0
A
0
9
0
7
3
9
0
8
3
9
0
8
7
9
0
A
3
9
0
A
7
Adaptive advanced preview control for 2 axes - - - - - - - B A
Auto sampling rate (Self-Learning control) - - - - B A A A A
Available for C series servo amplifier (Dead-band) - - - - A A A A A
Correspondence to High speed cycle retract - - - - - A A A A
Error output through check board - - - - A A A A A
High speed cycle cutting Skip function - - - - - B A A A
High speed interpolation (0.25ms) - - - - A A A A A
High speed interpolation (0.5ms) - - - - A A A A A
High speed interpolation for 2 axes - - - - - - - B A
IP or PI variable current control - - - - A B B A
Learning buffer expanding function - - - - - B A A A
Learning data transmission function - - - - - B A A A
Max. feed forward speed 196m/min for high speed I/F axis - - - - - A A A A
Mcmd output through check board - - - - A A A A A
New Hunting control function - - - - - - A -
Notch filter by current loop - - - - - - -
Preview repetitive control function - - - - A A A A A
Preview repetitive control improvement (5 -> 11) - - - - A A A A A
Preview repetitive control improvement (Posit or Veloc) - - - - A A A A A
Relieving restriction for Adaptive advanced preview control - - - - - A A A A
Self learning control - - - - A A A A A
Self learning control improvement (Expansion Gx etc.) - - - - A A A A A
Servo trace function - - - - A A A A -
Shock reducing function (Self-Learning control) - - - - B A A A A
Special Hunting control function - - - - - - -
Step Shock reducing function - - - - - B A A
Stopping motor function at alarm happened - - - - A A A A A
Tandem Learning function - - - - - - - B A
Torsion compensation during high speed cycle - - - - - B A A A
Torsion compensation for 2 axes - - - - - - - B A
Ultra-high precision feedback function - - - - - - A -
Variable Velocity feedback the latest 0.25msec or 0.5msec or 1msec
- - - - - A A A A
Velocity Control period 0.25msec - - - - A A A A A
Velocity feedback the latest 2msec - - - - - A A A A
Velocity Integral saturation (High-speed axis) - - - - - B A A
Servo Software
series
Functions
Functions for Editions of Servo Software series
