FS 16i/18i/21i-MA/MB, FS 16/18-MC, Improvement of Setting Rotation Axis with Rotary Scale Supplement to Manual Page 5

Supplement to Manual
NOTE:
The servo software reverses scale data depending to the following parameter setting.
PRM2018#0 PRM2022 Scale data
Case 1 0 111 Not reversed
Case 2 0 -111 Reversed
Case 3 1 111 Reversed
Case 4 1 -111 Not reversed
In “case 2” and “case 3”, please assign the threshold as the following example of setting P1867/P1868.
#2
Example of Setting P1867/P1868
Figure 1
“Case 1” and “Case 4”
Assuming tolerance of +- 15 degree for location of discontinuous point of scale data, setting of amount
P1867/P1868 must satisfy condition
Amount P1867/P1868 > 60000
“Case 2” and “Case 3”
Assuming tolerance of +- 15 degree for location of discontinuous point of scale data, setting of amount
P1867/P1868 must satisfy condition
Amount P1867/P1868 < (360000 – 60000) = 300000
#2
Figure 2
“Case 1” and “Case 4”
Assuming tolerance of +- 15 degree for location of discontinuous point of scale data, setting of amount
P1867/P1868 must satisfy condition
Amount P1867/P1868 > 100000
“Case 2” and “Case 3”
Assuming tolerance of +- 15 degree for location of discontinuous point of scale data, setting of amount
P1867/P1868 must satisfy condition
Amount P1867/P1868 < 360000 – 100000 = 260000
#2
Figure 3
“Case 1” and “Case 4”
Assuming tolerance of +- 15 degree for location of discontinuous point of scale data, setting of amount
P1867/P1868 must satisfy condition
Amount P1867/P1868 > 20000
“Case 2” and “Case 3”
Assuming tolerance of +- 15 degree for location of discontinuous point of scale data, setting of amount
P1867/P1868 must satisfy condition
Amount P1867/P1868 < 360000 – 20000 = 340000
A-78734EN
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Description
Date
FANUC Series 16i /18i /21i - MA/MB, 16 /18 -MC
Improvement of setting rotation axis
with rotary scale
2002/02/15
01 2002/02/15 O.Abe Newly registered
5/6
02 2002/05/28 O.Abe Out of frame #1 are altered
03 2002/08/11 Out of frame #2 are altered
O.Abe
#2
