FS 16i/18i/21i-MA/MB, FS 16/18-MC, Improvement of Setting Rotation Axis with Rotary Scale Supplement to Manual Page 7
Supplement to Manual
Parameters
#7 #6 #5 #4 #3 #2 #1 #0
1817 SCR
[Data type] Bit axis
SCR In order to set rotation axis (B type) in rotation axis with rotary scale which has no data
of revolution, scale data is
0: not transformed.
1: transformed.
NOTE
When this parameter is set, power must be turned off before operation is
continued.
Never set this parameter when rotation axis (B type) is not set, or when
discontinuous point of scale data does not exist in motion range.
1867 Threshold for transforming scale data (for all axes)
[Data type] 2-word
[Unit of data]
Increment system Unit of data
IS-A 0.01 deg
IS-B 0.001 deg
IS-C 0.0001 deg
#1
[Valid data range] 0 to 99999999
When scale data is larger than this parameter, scale data is transformed to continuous
data by subtracting value, corresponding to one rotation, from scale data. Be sure to
assign scale data outside of motion range in this parameter.
This parameter is for all axes and not effective in axis, in which parameter No.1868 is
set to a non-zero value.
NOTE
When this parameter is set, power must be turned off before operation is
continued.
P1867 is effective only for axes in which P1817#3 is set to 1.
1868 Threshold for transforming scale data (for each axis)
[Data type] 2-word axis
[Unit of data]
Increment system Unit of data
IS-A 0.01 deg
IS-B 0.001 deg
IS-C 0.0001 deg
#1
[Valid data range] 0 to 99999999
When scale data is larger than this parameter, scale data is transformed to continuous
data by subtracting value, corresponding to one rotation, from scale data. Be sure to
assign scale data outside of motion range in this parameter.
The parameter No.1867 is effective in axis, in which this parameter is set to 0.
A-78734EN
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Description
Date
FANUC Series 16i /18i /21i - MA/MB, 16 /18 -MC
Improvement of setting rotation axis
with rotary scale
2002/02/15
01 2002/02/15 O.Abe Newly registered
7/6
02 2002/05/28 O.Abe Out of frame #1 are altered
03 2002/08/11 Out of frame #2 are altered
O.Abe
