0i Mate - TC Operators manual Page 789

Operators manual

Page of 806

/ 806

APPENDIX

B–64134EN/01

G. ALARM LIST

765

SVPM

STATUS1

indica-

tion(*1)

Faulty location and remedyDescription

31 This hardware configuration does not allow the

spindle FAD function to be used. In this case, the

motor is not excited.

Check the CNC model.

33 This hardware configuration does not allow the

spindle EGB function to be used. In this case, the

motor is not excited.

Check the CNC model.

34 The spindle FAD function and spindle EGB func-

tion are both enabled. In this case, the motor is not

excited.

These two functions cannot be used at the same time.

Enable only either of them.

NOTE*2

SVPM contact signal

Between ESP and +24V on JX4 Contact open: Emergency stop

Contact closed: Normal operation

11) ALARM FOR FANUC SERVO MOTOR β series I/O Link Option

Alarm for FANUC SERVO MOTOR β series I/O Link Option can be confirmed by Power Mate CNC Manager

function.

Number Alarm type

000 to 299 Program or setting alarm

300 to 399, 401 Pulse coder alarm

400 to 499 (except 401) Servo alarm

500 to 599 Overtravel alarm

— System alarm or I/O Link alarm

ERROR CODES (SERIAL SPINDLE)

No. LED display Description Countermeasure

000

A parameter that requires power–down has

been specified.

Turn the power off, then back on.

011

The specified feedrate is zero. Check the feedrate parameter specified with a

function code.

013

The specified feedrate (maximum feedrate) is

zero.

Check the value of parameter No.043, which

indicates the maximum feedrate that can be

specified.

070

More than 32 blocks have been registered for a

buffering operation.

Reduce the number of registered blocks to 32.

090

Reference position setting cannot be executed

normally.

Move the tool in the direction of reference posi-

tion return in jog mode at a speed that causes

the servo position error to exceed 128. Then,

specify another reference position setting.
