Series 30i-Model A, Live Tool Control with Servo Motor Additional Manual Page 13

Additional Manual
A-79595E
Title
Draw
No.
Ed. Date Design Description
Date May.24.’04 esig. Apprv.
13/33
Sheet
FANUC Series 30i-MODEL A
Live Tool Control With Servo Motor
Address P signals MSP00 to MSP15<Fn160#0 to Fn161#7>
[Classification] Output signal
[Function] The P value specified last by the S_P_; command is output.
When extended spindle names are used, the value in parameter No.3781
corresponding to the spindle number of the spindle name specified last is
output.
[Output condition] When multi spindle control by using address P is enabled (bit 3 (MPP) of
parameter No. 3703 is 1), the P value specified in the S_P_;
command is output. When no S_P_; command has been specified even once
since power-up, the initial P value set in parameter No. 3775 is output.
When extended spindle names are used, the value in parameter No. 3781
corresponding to the spindle number of the spindle name specified last is
output. When no spindle name has been specified even once, the value set in
parameter No. 3775 is output.
Signal address
#7 #6 #5 #4 #3 #2 #1 #0
Gn026 *SSTP4
Gn027 *SSTP3 *SSTP2 *SSTP1
Gn029 *SSTP
Gn030 SOV7 SOV6 SOV5 SOV4 SOV3 SOV2 SOV1 SOV0
Gn521 SRVON8 SRVON7 SRVON6 SRVON5 SRVON4 SRVON3 SRVON2 SRVON1
Fn001 ENB
Fn038 ENB3 ENB2
Fn039 ENB4
Fn160 MSP07 MSP06 MSP05 MSP04 MSP03 MSP02 MSP01 MSP00
Fn161 MSP15 MSP14 MSP13 MSP12 MSP11 MSP10 MSP09 MSP08
Fn521 SVREV8 SVREV7 SVREV6 SVREV5 SVREV4 SVREV3 SVREV2 SVREV1
