Series 16i/160i - LA Descriptions Page 14

Descriptions
2.SPECIFICATIONS B-63192EN/03
- 8 -
Item Specifications
C series
Y series
YP series
Memory card input/output *1
Screen hard copy *1
Power mate CNC manager *1
Laser control function
Item Specifications
C series
Y series
YP series
Output power command
Pulse frequency command
5 to 2000 Hz (C series, Y series)
1 to 400 Hz (YP series)
Pulse duty command 0% to 100%
Piercing command
G24 including the high-speed piercing (C
series)
Assist gas command G32
Power override 0 to 200%
Duty override 0 to 150%
Frequency override 0 to 200%
Assist gas pressure override
0
to 200%
Power control Including the total power control
Waveform data registration G26
Execution priority data registration G25
Laser screen display
Pulse enhanced function
Oscillator control using an M code
External alteration of piercing time
Return light monitoring function
Beam output delay function
Laser status output signal
Purge completed, gas pressure under
control, base discharging, discharge start
ready, etc.
Tracing control G13, G14
Tracing interlock function **
Cutting condition setting function
Edge machining function
Start-up function
Step control
Optical path length compensation
Cutting restart function
High-speed machining function
Three-dimensional machining tool function
Item Specifications
C series
Y series
YP series
Attitude control A
Attitude control B
Interaction control
Hand coordinate system travel
W-axis tracing control
Circular interpolation of space
Three-dimensional coordinate conversion G68, G69
Near point search
Corner R insertion to space
