FANUC Series 16i/18i-MA Skip function EGB axis Additional Manual Page 4
Additional Manual
EDT
DATE
FANUC Series 16i/18i-MA
Skip function for EGB axis
Specifications
A－77401E
4 / 5
01 98.09.25 Newly registered
DESIG.
DESCRIPTION
TITLE
NO.
PAGE
K.Yasud
E.Genm
02 99.10.29 Page 5/5 was corrected.
4. Parameters
No. #7#6#5#4#3#2#1#0
6200 SRE HSS
[Data type] Bit type
HSS 0: The skip function does not use high-speed skip signals.
1: The skip function uses high-speed skip signals.
SRE When a high-speed skip signal is used:
0: The signal is considered to be input at the rising edge (0 to 1).
1: The signal is considered to be input at the falling edge (1 to 0).
No. #7#6#5#4#3#2#1#0
6208 9S8 9S7 9S6 9S5 9S4 9S3 9S2 9S1
[Data type] Bit type
9S1 - 9S8
Specify which high-speed skip signal is enabled when the G31.8 EGB skip
command is issued.
The bits correspond to the following signals:
0: The skip signal corresponding to the bit is disabled.
1: The skip signal corresponding to the bit is enabled.
9S1 ----- HDI0
9S2 ----- HDI1
9S3 ----- HDI2
9S4 ----- HDI3
9S5 ----- HDI4
9S6 ----- HDI5
9S7 ----- HDI6
9S8 ----- HDI7
