Multi C Executor for FANUC Series16i/18i/21i-MODEL B Supplement to Manual Page 4

Supplement to Manual
Edit
Apprv.
Apprv.Apprv.
Apprv.Desig.
Desig.Desig.
Desig.
Sheet
Title
Draw
No.
4/13
Date
DateDate
Date
Desi
g
n
Desi
g
nDesi
g
n
Desi
g
n
Descri
p
tion
Descri
p
tionDescri
p
tion
Descri
p
tion
Date
DateDate
Date
Multi C Executor for
FANUC Series16i/18i/21i-MODEL B
Specification
A
-76558E
04.09.10
S.ISOHATA
Master application ･･ Almost the same composition as usual user's application.
When the slave application program does not exist, it
operates as usual.
There is a functional limitation when the slave application
program exists.
Slave application 1,2･･ Multi application software made by FANUC.
(MANUAL GUIDE i、Tool Management Expansion 、SERVO GUIDE Mate)
3. Applied functions
3.1 Applied function on each Task
Followings are applied functions on each Task of Master(user's) application.
M A C W H
Standard function
○ ○ ○ ○ ×
Key input
○ × × × ×
Character display
○ × × ○*4 ×
Graphic display
○ × × ○*4 ×
File input/output
○ ○*1 ○*1 × ×
CNC/PMC window
○ ○*2 × ○*5 ○*6
Reader/Puncher interface
○ ○*3 ○*3 × ×
Reading F-ROM
○ ○*3 ○*3 × ×
Reading touch panel info
○ ○ ○ ○ ×
Floating point calculation
○ ○ ○ × ×
M: Main TASK A: Alarm TASK
C: Communication TASK W: Window TASK
H: High level TASK
○:Available ×:Not available
(*1) The same file cannot be accessed at the same time by two or more tasks.
Please make exclusive control process by the application program.
(*2) Busy error will occur if accessing simultaneously with the main task.
(*3) Please control the port or F-ROM reading exclusively in the application program.
(*4) The destination of the output of the display is not the normal screen but VGA window.
(*5) Exclusive control is necessary between other TASKs.
(*6) Only the limited function can be used.
