Multi C Executor for FANUC Series16i/18i/21i-MODEL B Supplement to Manual Page 9

Supplement to Manual
Edit
Apprv.
Apprv.Apprv.
Apprv.Desig.
Desig.Desig.
Desig.
Sheet
Title
Draw
No.
9/13
Date
DateDate
Date
Desi
g
n
Desi
g
nDesi
g
n
Desi
g
n
Descri
p
tion
Descri
p
tionDescri
p
tion
Descri
p
tion
Date
DateDate
Date
Multi C Executor for
FANUC Series16i/18i/21i-MODEL B
Specification
A
-76558E
04.09.10
S.ISOHATA
Appendix.1
Appendix.1Appendix.1
Appendix.1
Start up process of
Start up process of Start up process of
Start up process of M
MM
Multi C Executor system
ulti C Executor systemulti C Executor system
ulti C Executor system
(1) Loading of MEM file
・Do the loading of each MEM file into FROM, for master application and slave
application.
They are stored in F-ROM as following NAME.
Master application : CEX 1.0M, CEX 2.0M, CEX x.0M
Slave application : CS1 1.0M, CS1 2.0M, CS1 x.0M
(2) Setting of parameter
・Setting for making “Multi C Executor” effective
Confirm “Multi C Executor” option is ON.
・Parameter setting for master application(User’s application)
The way to set parameter for master application is the same as usual parameter
setting for C Language executor.
・Parameter setting for slave application(Fanuc application)
Regarding the way to set parameter for slave application, refer to the description
of the added parameter, described later, for Multi C Executor.
Note:
1. When the Multi C Executor is built into the system which has already used C
language executor, it is necessary to clear SRAM for C language executor to prevent
the malfunction because the SRAM mapping for Multi C Executor is different.
2. It can be judged whether the loading was correctly done from the series number
and version number information on the software of the system configuration screen.
Example of screen
Name Series Version
C_EX LIB BY01 3XXX Master application :Series/Version No. of library
C_EX APLI XXXX XXXX Master application : Series/Version No. of application
C_EX2 LIB BY01 3XXX Slave application 1 : Series/Version No. of library
C_EX2 APLI BX01 XXXX Slave application 1 : Series/Version No. of application
C_EX3 LIB BY01 3XXX Slave application 2 : Series/Version No. of library
C_EX3 APL BY33 XXXX Slave application 2 : Series/Version No. of application
